平推式全自動切條機及直紋,45度斜紋卷佈機適用於佈料、無紡佈、帳篷、雨傘、泡棉、皮革、反光材料、塑膠、紙張、雙麵膠、醋酸佈、補強帶、導電佈、銅箔等材料各種寬度直條，橫條及45度斜條的卷佈及裁切是服裝、箱包、鞋帽、服裝輔料、反光材料廠、帳篷廠、雨傘廠、電子廠等行業的理想選擇。
技術參數：
佈料幅寬：1.7米(另有2.05米、2.4米可選)
佈料轉速：0-800 (轉/分鐘) 切佈直徑：300毫米，也可定製400毫米、500毫米
佈軸直徑：37毫米 佈料 電機功率：0.75千瓦
刀片電機功率：1.5千瓦 最小切條寬度：2毫米
電壓：380V/220V可選
外形尺寸：2.7米x0.75米x1.4米
配備特點：
1.主軸以及圓刀使用無級變速系統，可做高低無級調速及正反轉切換控製。
2.采用進口PLC及進口高精密步進系統控製切割寬度及進退刀切割系統，配合進口精密滾珠絲桿及滑軌移位，高壽命，不易磨損，使切割寬度的精度達到0.1mm，最窄切割寬度為進刀切割時平行快速推進，速度采用無極調速，紙管容易切斷，達到高精度快速切出高品質的產品。
3.操作界麵采用LCD中文顯示屏，所有操作，隻需要一個畫面，可同時設定四種分切寬度和次數，並顯示實際切割次數，並設有手動/自動轉換功能
4.配備雙麵磨刀系統，采用金剛石砂輪磨削，經久耐用，不易發熱，刀片磨後光潔度高，使用壽命是普通白玉剛砂輪的十倍，刀片不用拆卸，即可磨刀。刀片長期保持鋒利，達到最佳裁切質量，並附有自動吸塵裝置，保持佈料及軌道清潔。
5.采用快速放料設計，一步到位。上料下料隻須一個動作即可完成。
6.電路采用各個獨立控製系統，每條線都做有標號，診斷維修簡單快捷，不易出故障。
7.夾佈卡盤配有安全防護罩，不傷人。
8.電線配有工程塑料鏈條保護，電線不容易折斷，不容易老化。
Application:
New Deliveries Cutting Machines,Straight strap and 45-degree diagonal cloth rolling machine suitable for cloth ,adhesive-bonded fabric ,tent,umbrella,sponge foam,leather,reflective material,plastic,paper,two-slide glue,acetate fabric ,reinforced belt ,conductive cloth,copper,foil and other materials of various width straight .The idea choice of industries of clothing,bags,footwear,hats,garment subsidiary material,reflective material facotory ,tent factory,umbrella factory,transformer factory,electorn factory and other indusries.
Technical parameters:
Width:1.7m(2.05m,2.4m optional)
Rotating Speed of Cloth Roll: 0-800rpm/min
Cloth Diameter: 300 mm, 400 mm、500 mm can also be customized
Diameter of Cloth Roll:37mm
Power:0.75kw
Blade power:1.5kw Minimun
Width of Cut Strap:2mm
Voltage:380V/220V optional Machine
Measurement:2.7m×0.75m×1.4m
Feature:
1.Circular knife spindle, and use the CVT system, do the level of variable speed and reversing switch.
2.imported PLC and control system, imported high-precision cutting width and step retreat knife cutting systems, precision ball screw and imported with the shift rail, high-life, easy to wear, so that the width of the cutting Accuracy of 0.1mm, the narrowest cutting width of 2mm, cutting parallel to the fast feed advance speed with stepless speed, paper tube is easy to cut, to quickly cut out high-quality precision products.
3.The user interface with LCD Chinese display, all operations, only one screen, which can set four kinds of cutting width and frequency, and show the actual cutting times, and with manual / automatic conversion
4.With double-sided sharpening system that uses diamond grinding wheel, durable, easy to heat, high finish after grinding blades, grinding wheels of life ten times the ordinary Baiyu Gang, without disassembling The blades, you can knife. Long-term sharp blade, to achieve the best cutting quality, along with automatic cleaning devices to keep track of cloth and clean.
5.Using fast discharge design, in one step. Cutting only on the material to complete an action.
6.Each individual circuit control system, each line has done a label, diagnostic maintenance quick and easy, not easy to fail.
7.Buka folder with security cover plate, not hurt.
8.Chain with a plastic wire protection, cable is not easily broken, is not easy to short time using .
