軸徑 型號 重量 尺寸 基本額定載荷 極限轉速 推力墊圈
Shaft Designation Mass Dimensions Basic Load Ratings Limiting Thrust Washer
Diameter 　 　 Dc1 D1 D  B B1 動  Cr 靜  Cor Speed AS LS
　 　 　 　 　 　 　 　 Dynamic Static 　 　 　
mm 　 g 　 　 　 　 min. kN kN rpm 　 　
10 AXW 10 8.5  10 14 27 3.2  3.0  9.2  25.5  6000 AS 1024 LS 1024
12 AXW 12 9.0  12 16 29 3.2  3.0  9.9  29.0  5500 AS 1226 LS 1226
15 AXW 15  10.0  15 21 31 3.2  3.5  11.3  36.0  4200 AS 1528 LS 1528
17 AXW 17  11.0  17 23 33 3.2  3.5  11.9  39.5  3800 AS 1730 LS 1730
20 AXW 20  14.0  20 26 38 3.2  3.5  13.1  46.5  3600 AS 2035 LS 2035
25 AXW 25  20.0  25 32 45 3.2  4.0  14.7  58.0  3100 AS 2542 LS 2542
30 AXW 30  22.0  30 37 50 3.2  4.0  16.3  70.0  2600 AS 3047 LS 3047
35 AXW 35  27.0  35 42 55 3.2  4.0  17.8  81.0  2300 AS 3552 LS 3552
40 AXW 40   39.0  40 47 63 4.2  4.0  28.0  114.0  1900 AS 4060 LS 4060
45 AXW 45  44.0  45 52 68 4.2  4.0  30.0  128.0  1700 AS 4565 LS 4565
50 AXW 50  49.0  50 58 73 4.2  4.5  32.0  143.0  1500 AS 5070 LS 5070

說明： 　 　 　 　 　 　 　 　 　 　 　 　
1.表中所列基本額定載荷、極限轉速和重量，僅供選擇參考用。 　 　 　 　
2.脂潤滑時，極限轉速為表列數值的25%。 　 　 　 　 　 　 　 　

Note: 　 　 　 　 　 　 　 　 　 　 　 　
1.These load, speed and mass is reference of choice only.
 　 　 　 　

2.With grease lubrication, 25% of these limiting speed will apply.

推力滾針和保持架組件 AXK

TYPE DC1(mm) DC(mm) DW(mm)
AXK0414TN 4 14 2
AXK0515TN 5 15 2
AXK0619TN 6 19 2
AXK0821TN 8 21 2
AXK1024 10 24 2
AXK1226 12 26 2
AXK1528 15 28 2
AXK1730 17 30 2
AXK2035 20 35 2
AXK2542 25 42 2
AXK3047 30 47 2
AXK3552 35 52 2
AXK4060 40 60 3
AXK4565 45 65 3
AXK5070 50 70 3
AXK5578 55 78 3
AXK6085 60 85 3
AXK6590 65 90 3
AXK7095 70 95 4
AXK75100 75 100 4
AXK80105 80 105 4
AXK85110 85 110 4
AXK90120 90 120 4
AXK100135 100 135 4
AXK110145 110 145 4
AXK120155 120 155 4
AXK130170 130 170 5
AXK140180 140 180 5
AXK150190 150 190 5

AS 0414 AS0414
AS 0515 AS0515
AS 0619 AS0619
AS 0821 AS0821
AS 100135 AS100135
AS 1024 AS1024
AS 110145 AS110145
AS 120155 AS120155
AS 1226 AS1226
AS 130170 AS130170
AS 140180 AS140180
AS 150190 AS150190
AS 1528 AS1528
AS 160200 AS160200
AS 1730 AS1730
AS 2035 AS2035
AS 2542 AS2542
AS 3047 AS3047
AS 3552 AS3552
AS 4060 AS4060
AS 4565 AS4565
AS 5070 AS5070
AS 5578 AS5578
AS 6085 AS6085
AS 6590 AS6590
AS 7095 AS7095
AS 75100 AS75100
AS 80105 AS80105
AS 85110 AS85110
AS 90120 AS90120
