Sensor Type

 Strain Gauge(350????????????????) 2 or 4

 Sensor Inputs

 +5V and -5VDC(10V) at 70mA maximum Short & Open Circuit protected

 Analog Output

 0~2.5VDC, 3.5mm Stereo Phone Jack

 Sensitivity

 HighGain 0.057????????????????/V - 0.625????????????????/V

 Low Gain 0.568????????????????/V - 5.00????????????????/V

 Automatic Zero

 Automatic Circuits maintain true zero during periods between

 Balance

 Measurements. This assures sensor and

 instrument accuracy regardless of ambient temperature excursions.

 Manual Zero Balance

 ± 1????????????????/V

 Gain Control

 Low Gain(×1) Gain modulus : 40 ~ 440

 High Gain (×10) Gain modulus : 400 ~ 4400

 Frequency Response

 0 ~ 1????????????????

 Speed

 0 ~ 400 SPM(Threshold Trigger)

 400 ~ 3000 SPM(Cam Probe Trigger)

 Digital Display

 5-Digit × 3 or 5-Digit × 5

 Cam Input

 10~30VDC, Maximum 50???????????????? NPN or PNP

 Proximity Switch or Limit Switch

 Relay Output

 NC, NO Contact, 10A (AC120V)

 Computer Interface

 RS 485 / 232 (Option)

 Security

 Security Key jumper provides protection to the monitor settings from being

 Changed by

 Unauthorized person.

 Power Requirement

 3W, 90~130VAC (50/60????????????????) or 170~280VAC (50/60????????????????)

 Operating Temperature

 0 ~ 70℃

 Weight

 Approximately 4.3㎏

1

DISPLAY (TOTAL)

負重,調定點,顯示計數器,顯示小數點和字母

2

DISPLAY (CH1)

顯示各信道的負重,2個和4個的感應信通上輸入各種數據,

3

DISPLAY (CH2)

在正麵 左/右側和後麵的左/右測顯示負重。

4

DISPLAY (CH3)

 SKL-90□ Model是 2個還有4個的感應信通上顯示信號

5

DISPLAY (CH4)

 - SKL-902(左1CH,右2CH), SKL-904(正麵左1CH,右2CH/後麵左3CH,右4CH)

6

HIGH S/W

設置上限負重時使用

7

LOW S/W

設置下限負重時使用

8

RESET S/W

用於重設警告和基礎負重標示及模式的 ENTER KEY

9

UP S/W

增加各種設置值時使用

10

DOWN S/W

減少各種設置值時使用

11

ALARM LED

進入警報狀態，繼電器運作時亮燈
