VMC714立式加工中心
Vertical Machining Center
用途Usage
適用於機械加工及模具制造領域的立式加工中心，能適應從粗加工到精加工的加工要求，可完成銑、鉆、攻、鏜等多種工序。
Widely used inmachining and tooling for manufacturing vertical machining centers,able to adapt from roughing to finishing the processing requirements, to be completed by milling, drilling, tapping, boring and many other.
特點Feature
○VMC系列立式加工中心是格魯寶機床公司引進先進技術生產的新一代數控機床，該機床獨特的淬火硬軌貼塑導軌副，不僅適用於板類、盤類、殼體類、精密零件的加工。機床帶有自動刀具交換系統（ATC），全封閉式防護罩，自動潤滑系統，冷卻系統，自動排屑裝置，手動噴槍及便攜式手動操作裝置（MPG），零件一次裝夾後可完成銑、鉆、擴、鉸、攻絲等多工序加工，具有自動化程度高，可靠性強，操作簡單，方便，宜人，整體造型美觀大方，機電一體化程度高等優點。
○VMC series Vertical Machining Center is the machine tool of a new generation produced by GLOBE Machine Tool Company with introduction of the advanced technology. The distinctive hardening plastic coated hard rail guide way of the machine tool is not only suitable for processing of precision parts like plate, disc and shell, but also applicable for mould process. It has the ATC system, fully enclosed protective shield, automatic lubrication system, cooling system, automatic chip removal device, manual spray gun and portable MPG. The parts after the first clamping can complete many machining processes including milling, probing, expending, hinging and tapping and featured by the advantages of high degree of automation, high reliability, easy and pleasant operation, nice overall shape, as well as high degree of mechanical and electrical integration.
技術參數Technology data
項目 | Item | VMC714 |
工作臺尺寸mm | Pallet size | 1000×400 |
左右行程（X）mm | X axis travel | 600 |
前後行程（Y）mm | Y axis travel | 400 |
上下行程（Z）mm | Z axis travel | 500 |
主軸中心至立柱導軌距離mm | Distance from spindle center to column guide | 457 |
主軸端面至工作臺面距離mm | Distance from spindle nose to table | 110-610 |
工作臺T型槽 | T-type tank | 3-14×110 |
主軸錐孔 | Type of taper hole | BT40 |
主軸最高轉速rpm | Max spindle speed | 8000 |
主軸馬達功率kw | Spindle power | 3.7/5.5 |
X.Y.Z軸伺服電機kw | Three-axis servo power motor | 1.0/1.0/1.5 |
X.Y.Z電機連接方式 | Three-axis motor coupling | Direct Torque motor |
X.Y.Z軸導軌方式 | Three-axis rail-way | Slide-rail |
工作臺最大荷重kg | Max. weight on pallet | 500 |
換刀速度sec | Tool changing time(tool-to-tool) | 1.8 |
選刀方式 | Tool selection mode | The nearest |
刀庫容量pcs | Tool storage capacity | 16(Carousel) |
最大刀具重量kg | Max. tool weight | 8 |
最大刀具長度mm | Max. tool length | 250 |
最大刀具直徑mm | Max. tool diameter | φ90 |
XYZ快移速度m/min | Rapid traverse rate | 10/10/10 |
切削進給速度m/min | Cutting feed speed | 8 |
XYZ定位精度mm | Positioning precision | ±0.008/±0.006/±0.006 |
XYZ重復定位精度mm | Repeatability | ±0.004/±0.004/±0.004 |
機器外形mm | L×W×H | 2700×2250×2700 |
機床總重kg | Weight | 3500 |
近年來滕州市政府著力打造工業機械生產基地，格魯寶商貿公司在市經信局機電辦、市機械協會的指導下，致力於將滕州優質的機械產品以最優的價格帶給廣大用戶，讓更多的客戶獲得更新、更好的技術。詳情訪問：www.tzglobe.com/或www.gelubao.com電話：06325266449 13863237018 QQ：1260650009
