We will respond to customer's request by plating gold, silver or nickel on tungsten and molybdenum wires and various other wires.
(1)Plating materials
Gold,Silver, Copper, Nickel, Palladium, Copper-Tin
(2) Standard specification for plating
Type | Process |
Plating metal-material name | drawing − EP* − gold plating |
（Ex. Au-TWG：Gold-plated tungsten wire） |
(3) Applicable size of plated wire適用於鍍線的大小
φ0.005~φ0.40mm
(4) Plating thickness and tolerance鍍層厚度和寬容
plating thickness t (μm) | Tolerance |
0.10≦t<0.60 | ±0.20μm |
0.60≦t<1.00 | ±0.20μm |
1.00≦t<2.00 | ±0.25μm |
2.00≦t≦10.00 | ±0.30μm |
※ Contact us for the plating other than
our standards and its plating thickness.
