● GENERAL SPECIFICATIONS
Cable Interface  F-connector, female, 75??1??71??1??776??1??71??1??778
CPE Network Interface  10/100Mbps Ethernet
Power Outlet  –
Reset Button  –
Power Supply  5W (nominal)

● ENVIRONMENTAL
Operating Temperature  0 to 40℃
Storage Temperature  -30 to 70℃
Operating Humidity  5 to 95% R.H. (non-condensing)
DOWNSTREAM
Modulation  64 or 256QAM
Channel Rate  ≤55Mbps
Bandwidth  8MHz or 6MHz
Symbol Rate  6.952Msym/s

● UPSTREAM
Modulation  8, 16, 32, 64, 128QAM or QPSK
Channel Rate  ≤30Mbps
Bandwidth  200K, 400K, 800K, 1.6M, 3.2M, 6.4M
Symbol Rate  160, 320, 640, 1280, 2560, 5120Ksym/s
Operating Level Range
A-TDMA:
68 to 114dBμV@32,64QAM
68 to 115dBμV@8,16QAM
68 to 118dBμV@QPSK
S-CDMA
68 to 113dBμV
Output Impedance  75??1??71??1??776??1??71??1??778(nominal)
Output Return Loss  ≥8dB (5 to 65MHz)
Frequency Range  5 to 65MHz ± 30KHz(edge to edge)
