閥型號 | 介面尺寸 | 孔徑 | 最高壓力差 | 最大工作壓力 | Kv因子 | 名義製冷量(液體功率) | |||
VALVE | CONNECTION | PORT SIZE | M.O.P.D. | MAX PRESSURE | Kv FACTOR | NOMINAL CAPACITY(kW) | |||
TYPE | SIZE | (mm) | (bars) | (bars) | m3/hr | R12 | R22 | R404A/R502 | R134a |
1020 / 2 | 1/4" Flare | 2.5 | 21 | 30 | 0.175 | 2.50 | 3.15 | 2.08 | 2.95 |
1020 / 3 | 3/8" Flare | 3.0 | 21 | 30 | 0.230 | 3.30 | 4.15 | 2.75 | 3.90 |
1028 / 3 | 3/8" Flare | 3.0 | 21 | 30 | 0.230 | 3.30 | 4.15 | 2.75 | 3.90 |
1064 / 3 | 3/8" Flare | 7.0 | 21 | 30 | 0.800 | 11.45 | 14.50 | 9.50 | 13.50 |
1064 / 4 | 1/2" Flare | 7.0 | 21 | 30 | 0.800 | 11.45 | 14.50 | 9.50 | 13.50 |
1070 / 4 | 1/2" Flare | 12.5 | 21 | 30 | 2.200 | 31.50 | 39.60 | 26.20 | 37.10 |
1070 / 5 | 5/8" Flare | 12.5 | 21 | 30 | 2.610 | 37.20 | 47.00 | 31.00 | 44.00 |
1090 / 5 | 5/8" Flare | 16.5 | 21 | 30 | 3.800 | 54.20 | 68.50 | 45.20 | 64.00 |
1070 / 6 | 3/4" Flare | 17 | 21 | 30 | 4.300 | 61.50 | 77.50 | 51.20 | 72.45 |
1090 / 6 | 3/4" Flare | 16.5 | 21 | 30 | 5.700 | 81.30 | 102.60 | 67.85 | 96.00 |
1028 / 2 | 1/4" ODS | 2.2 | 21 | 30 | 0.150 | 2.15 | 2.70 | 1.80 | 2.55 |
1068 / 3 | 3/8" ODS | 7.0 | 21 | 30 | 0.800 | 11.45 | 14.50 | 9.50 | 13.50 |
1068 / 4 | 1/2" ODS | 7.0 | 21 | 30 | 0.800 | 11.45 | 14.50 | 9.50 | 13.50 |
1078 / 4 | 1/2" ODS | 12.5 | 21 | 30 | 2.200 | 31.50 | 39.60 | 26.20 | 37.10 |
1078 / 5 | 5/8" ODS | 12.5 | 21 | 30 | 2.610 | 37.20 | 47.00 | 31.00 | 44.00 |
1098 / 5 | 5/8" ODS | 16.5 | 21 | 30 | 3.800 | 54.20 | 68.50 | 45.20 | 64.00 |
1078 / 6 | 3/4" ODS | 17 | 21 | 30 | 4.300 | 61.50 | 77.50 | 51.10 | 72.45 |
1098 / 6 | 3/4" ODS | 16.5 | 21 | 30 | 5.700 | 81.30 | 102.60 | 67.85 | 96.00 |
1098 / 7 | 7/8" ODS | 16.5 | 21 | 30 | 5.700 | 81.30 | 102.60 | 67.85 | 96.00 |
1078 / 9 | 1-1/8" ODS | 25.5 | 21 | 30 | 10.000 | 143.00 | 180.00 | 119.00 | 168.50 |
1079 / 7 | 7/8" ODS | 12.5 | 21 | 30 | 2.610 | 37.20 | 47.00 | 31.00 | 44.00 |
1099 / 9 | 1-1/8" ODS | 16.5 | 21 | 30 | 5.700 | 81.30 | 102.60 | 67.85 | 96.00 |
1079 / 11 | 1-3/8" ODS | 25.5 | 21 | 30 | 10.000 | 143.00 | 180.00 | 119.00 | 168.50 |
1079 / 13 | 1-5/8" ODS | 27.0 | 21 | 30 | 16.000 | 228.80 | 288.00 | 190.50 |
