TP188FM
Type: Single cylinder,Forced Air Cooling,4-Stroke
Rated power (kW/3000rpm):9.0
Max. Torque (N.m/2500rpm):26.5
Fuel tank volume: 6
Fuel consumption (g/kW.h):
less than 395
Oil consumption (g/kW.h):
less than 6.8
Min. stable unloaded speed (more or less 100r/min):1350
Speed Fluctuating Ratio:
lower than 10%
Transmission Mode(r/Min):
Reduction Ratio:
Noise(lower than): 104db(A)
Bore*troke (mm):90*66
Displacement (cc):420
Compression Ratio:8.3:1
Lubricating mode: Splashing
Starting Mode: Recoil start (Electric starting)
Machine oil Designation: engine oil for vehicle SAE#20, #30
above 10W-30 SE for cold area
Fuel Designation:
petrol for vehicle use
Rotation: Anti-clockwise (from output)
Valve Clearance: input valve0.10~0.15mm,output valve 0.15~0.20mm
Spark plug clearance: 0.6~0.8mm
Igniting Mode: Transistor Electric, inductive Firing
Air cleaner: Half-dry, Oil immersed, Foam filter
Dimension (L*W*H):405*450*443
Net weight (kg):31
