1.設計合理,結構簡潔。
2.單片機、步進電機控製,袋長設定方便,準確。
3.調速簡單、快捷。
4.自動完成製袋、充填、計數、封口、切斷的全部包裝過程。
5.文本顯示屏操作,調整方便,自動化程度高。
6.先進的光電數控製袋系統、下膜平穩準確,製袋長度能在操作麵直接設定。
7.光標對版,可獲得準確的商標圖案。
8.該機據不同物料可選配螺桿或量杯計量裝置。
9.可選配色帶打碼機、充氣裝置(氣源自備)。
(1)Reasonable design, simple structure.
(2)Controlled by single-chip computer, stepping motor, convenient
and correct bag length setting.
(3)Simple, fast speed regulation.
(4)Automatic completion for bag-making, filling, counting, sealing and cutting
(5)text display screen operating, convenient adjustment, high automation.
(6)Advance sensor digital-control bag making system, stable, correct bottom film run, bag length can be directly set up at operating side.
(7)Plate alignment by cursor, correct brand design can be achieved.
(8)Metering screw stem or glass devices can be optional in this machine according to different materials.
(9)Optional: ribbon coding machine. , gas-filled device (air source supplied by users).
適用於醫藥、食品、植物種子、化工產品等有一定流動性、松散無粘性粉狀、顆粒狀物料的自動包裝,如:奶粉、麵粉、沖劑、小丸、味精、白糖、湯料、麥片、乾燥劑等。
Suitable for automatic packaging liquid, loose non-adhesive powder, particle materials like milk powder, flour, gourmet, sugar, soup, wheat and drying agents.
包裝速度 | Packing speed | 60-100bags/min |
製袋尺寸 | Bag-making size | (L)30-200mm (W)50-150mm |
計量范圍 | Filling range | 10-200ml |
包裝材料 | Packing materials | OPP/CPP PET/PE 等復合材料 |
包裝膜寬 | Film width | 100-300mm |
薄膜厚度 | Film thickness | 0.03-0.10mm |
耗氣量 | Air consumption | 0.36m3/min 0.6MPa |
電源功率 | Power supply | AC220V 50-60Hz 1.5kw |
機器尺寸 | Machine dimensions | (L)700×(W)900×(H)1750mm |
整機重量 | Machine weight | 300kg |
