整機特點：
◆ 機械前緣送紙系統、變頻調整風量，送紙準確、穩定。
◆ 開槽部采用電動或手動橫移。
◆ 選用優質材料及配件。
◆ 所有輥軸鍍鉻，增強硬度。
◆ 傳動采用45#精密齒輪、噴淋式循環潤滑系統.
◆ 應用免鍵連續環，減少中心磨損，虛位放大，保持長期印刷套準。
◆ 采用掛版機構，自動復位、換單快捷。
◆ 各單元設置急停開關、防護操控安全。
◆ 間隙調整采用自鎖式調整裝置，操作方便。
◆ 電氣元件、主關軸承、氣動控製元件等采用國內品牌。
◆ 配備自動收紙堆碼機。
◆ 計速器顯示生產速度，計數器生產數量。
主要技術參數Main Technical parameter:
Machine Features:
◆ Mechanical lead edge feeder system，,inverter adjust air volume, feeding is precision and steady.
◆ Adapting imported PLC with touch screen control. It can save order, and accelerate the changing order speed.
◆ Adopt high quality material and assembly part.
◆ All cylinders and rollers are chrome plated for ideal hardness.
◆ Transmission gears from 45# precision grinded alloy steel and with spraying type circulating lubrication system.
◆ Use expansion sets tight link to reduce abrasion of the shaft, keep high precision of the machine in long year.
◆ Adopt hanging structure, auto reset, quick changing order.
◆ Each unit is equipped with Emergency Stop switch to ensure safety operation.
◆ Using Self Locking gap adjustment device for ease operation.
◆ Electric element, bearing, and pneumatic element all use domestic famous brand.
◆ Mechanical lead edge feeder system,inverter adjust air volume,feeding is precision and steady.
◆ Equipped with automatic paper stacking machine
◆ Speed meter displays production speed ,and counter displays production quantity.
| 色組 Color Group | 可按用戶需要配置 Everyting can be quipped accord to users' needs | |||||
| 印刷用紙 Printing Paper | A、B、C、A/B、B/C和A/B/C瓦楞紙板（C最大間隙13mm） | |||||
| 機械速度 Economy speed | 80片/分(sheets/min) | |||||
| 印刷滾筒直徑 Printing Roller Dia | φ300 | φ400 | φ480 | φ530 | φ620 | |
| 最小過紙高度 Min.paper size | 260 | 300 | 350 | 400 | 450 | |
| 印刷寬度 Printing width | 1800mm-3000mm(用戶定製) | |||||
| 標準印刷厚度 Standard printing Plate Thickness | 4-9mm | |||||
| 開槽寬度 Slot width | 7mm（可定製） | |||||
| 最小開槽近距 Min.Slot Space | 正刀160×160×160×160 | |||||
反刀300×60×300×60  | ||||||
