burkert 2861比例閥基於burkert 2871型改造的比例閥 Type 2861 is an extremely compact solenoid control valve and is available with an orifi ce up to 2mm. It is based on the standard version of Type 2871 (see datasheet). burkert 2861比例閥基於burkert 2871型改造的比例閥 It is used as an actuator in closed control loops (pressure, fl ow, temperature, etc.). burkert 2861比例閥基於burkert 2871型改造的比例閥 Compared with the standard version, the valve is essentially of simpler construction and assembly and testing procedures are optimized, easing high volume series production with shorter delivery times. burkert 2861比例閥基於burkert 2871型改造的比例閥 Please follow the instructions for a customised design on page 5 of this datasheet.

burkert 2861比例閥基於burkert 2871型改造的比例閥特點

1. Made for custom engineered applications
2. Orifice sizes DN 0.8 ... 2.0 mm
3. Port connection 1/8”, sub-base or custom engineered armature

burkert 2861比例閥基於burkert 2871型改造的比例閥參數：

burkert 2861 Body material Brass, stainless steel
burkert 2861 Seal material FKM, EPDM on request
burkert 2861 Medium Neutral gases, liquids on request
burkert 2861 Pressure range 0 ... -12 bar 2)
burkert 2861 Medium temperature -10 ... +90 °C
burkert 2861 Ambient temperature max. +55 °C
burkert 2861 Power supply 24 V DC
burkert 2861 Max. current 220mA (at 24V-hold)
burkert 2861比例閥基於burkert 2871型改造的比例閥
burkert 2861 Power consumption 5 W
burkert 2861 Duty cycle 100% continuously rated
burkert 2861 PWM control frequency 800 Hz
Port connection Sub-base , G 1/8, NPT 1/8, others on request
burkert 2861 Electrical connection Cable plug Type 2507, Form A industrial standard
Item no. 423 845
Installation As required, preferably with actuator in
upright position

burkert 2861比例閥基於burkert 2871型改造的比例閥

burkert 2861比例閥基於burkert 2871型改造的比例閥
