| 系列/規格 (specification): | |||||||||
| 麵 料 (fabric) | 操作系統 (system) | ||||||||
| ~ 拉珠(有膠珠及鋼珠供選擇) (ball chain- | |||||||||
| ~ 遮光麵料 (blackout) | ordinary or metallic is available for chosing | ||||||||
| ~ 仿金屬麵料(metallic) | ~ 普通彈簧 (oridinary spring) | ||||||||
| ~ 陽光麵料(sun screen) | ~ 慢速彈簧 (speed -reduce spring) | ||||||||
| ~ 防污麵料 | |||||||||
| 其中陽光麵料有以下范圍可供選擇- | 網空率(openness factor) ~ 3-9% | ||||||||
| (available alternatives) - | 顏色color ~ 單色,雙色,及三色交織 | ||||||||
| (single or mixed weaving) | |||||||||
| 紋路圖案 ~方格，菱形，斜紋及條紋系列 | |||||||||
| (pattern square,basket,twill & stripe) | |||||||||
| 工藝參數(technical data): | |||||||||
| 頂通 (tube rail)- | |||||||||
| ~ 直徑(diameter)- 38mm also available | |||||||||
| ~ 鋁材厚度(material thickness) 0.8-1.2mm | |||||||||
| 最小寬度要求 | 最大寬度 | 最大高度 | 最大麵積 | 最大吊重力 | |||||
| (min.width required) | (max. width) | (max. height) | (max. area) | (max. wt. Loaded) | |||||
| 拉珠 | 16 cm | 250 cm | 450 cm | 8 M2 | 4 kgs | ||||
| 普通彈簧 | 66 cm | 200 cm | 180 cm | 3.5M2 | 1.9kg | ||||
| 慢速彈簧 | 66 cm | 250 cm | 250 cm | 3.5M2 | 1.95 kg | ||||
| *如用戶要求工藝超出上述范圍，該產品則不受本公司的保修條款保障 | |||||||||
| *(product would not be under warranty if orderd specification was over anove shown limit) | |||||||||
