K2-10 Concentricity Gage is comprised of three main components for assembly. #1) selection of standard or precison accuracy, #2) selection of main rollers, #3) selec an indicator(s) and/or other accessories. Their are two classifications calibrated and directly traceable to (N.I.S.T.), Standard Black Gages are guaranteed to be better than ≤ 4µm (.00016") accuracy. Precision Gold Gage is guaranteed better than ≤ 2µm (.00008”) accuracy.

#KK2-10 Standard Concentricity Gage Model
#KK2-10P Precision Concentricity Gage Model

Gage Specifications:

Diameter Capacity: 1/8" to 1" (3mm to 25mm)
Diameter Zero Capaicity: 3/32" to (1mm)
Length Capasity: ≤ 4" (102mm)
Standard Accuracy: ≤ 4µm (.00016”)
Precision Accuracy: ≤ 2µm (.00008”)
Gage Length: 10.5" (267mm)
Gage Width: 4.5" (114mm)
Shipping Weigth: 4.9lbs. (2.2kg.)

Main Roller Slection

#110-10FP Full Plain Rollers Set

#110-10HP Half Plain Rollers Set
#110-10QP Quarter Plain Rollers Set
#110-10FZ Full Plain Zero Rollers Set
#110-10HZ Half Plain Zero Rollers Set
#110-10QZ Quarter Plain Zero Rollers Set
#110-10TZ Extra Thin Zero Rollers Set
#110-10TM *Thread Mandrel Rollers Set
