應用行業/Applicable Industry
適用於:石雕,磚雕,玉雕,墓碑,裝飾裝潢,園林藝術,工藝品;可加工材質:大理石、玉石、瓷磚、人造石、玻璃、銅、鋁、鐵等材質
Suitable for industries such as billboards, model industry, electronics and electic appliances, decoration industry, toys and gifts, furniture manufacturing, etc; Available materials: acrylic, double color boards, plastic, wood, ABS, PVC, MDF, PCB, copper, aluminium and various non-ferrous metals
產品描述:
1.整體鑄造鐵床身,回火處理和二次精密加工;橫梁與立柱為加寬加厚設計,可以一刀雕刻10MM天然大理石
2.設備使用自動水循環系統與水槽設計,確保刀具更長使用受命
3.整機采用防水設計,確保傳動部位與電路部位的耐用與安全
4.主軸電機為大功率水冷變頻主軸,防水設計
1.The overall body cast iron beds, and secondary tempering precision machining; thick beams and columns for the widened designed to 10MM natural marble carving knife
2.The device with automatic water system and tank design, to ensure that longer use of the tool was ordered
3.The machine uses water-proof design, to ensure transmission parts and circuit parts of the
4.Spindle motor frequency spindle high power water-cooled, water-proof design
技 術 參 數:
產品型號/Model | JY-S1318 |
工作行程/Working area | 1300*1800*120mm |
外觀尺寸/Volume | 2400*1920*1350mm |
主軸功率/Main axle power rate | 2.2/3/4.5KW(可選) |
主軸轉速/Main axle rotating speed | 6000-24000 rpm/min |
最大加工速度/Max.Working speed | 6000mm/min |
最大進料高度/Feeding height | 120mm |
刀柄直徑/Engraving tools | 3.175/4/6/12.7mm |
重復定位精度/Repositioning Accuracy | 0.01mm |
文件格式/Supported File Format | DXF,PLT,G代碼,MMG,U00,NC,ENG |
工作電壓/Power | AC220V(380V)/50HZ AC110V/60HZ(可選) |
整機重量/Weigth | 750kg |
