ESD Shoes & Heel Strap Testing
• Electrical resistance of ESD shoes and heel straps is
measured and compared to preset limits.
• Set value for the upper and lower resistance limits can be
varied. Upper limit: 10M ohms, 35M ohms, or 100M ohms.
Lower limit: 100k ohms (1.0M ohms).
• LCD display (3 digit) indicates actual resistance
measurement value.*
• LED’s on the tester indicate Low, OK, and High test results.
• Measurement requires standing on the Shoe Testing Plate
and pressing the touch panel.
*Includes body resistance

Wrist Strap Testing
• Electrical resistance of wrist straps is measured and
compared to preset limits.
• Set value for an upper resistance limit can be varied. (5M
ohms, 10M ohms and 35M ohms). Lower resistance limit
650K ohms preset internally.
• LCD display (3 digit) indicates actual resistance
measurement value.**
• LED’s on the tester indicate (Low, OK and High) test results.
• The measurement requires inserting ground cord plugs
into a test jack and pressing the touch panel.
**Includes arm to wrist band contact resistance
