    供應模具檢出裝置RM1310
    商品代碼: 11578109
    (可點擊以下立即詢價直接線上諮詢,或來電提供此商品代碼諮詢)
    即日起提供日本樂天代購服務-詳見 Rakuten-suki日本樂天代購,謝謝。
    商品詳細說明
    加工定製 類型 模具檢出裝置 品牌 RIKEN KEIKI
    型號 RM1310 適用范圍 模具保護 產品別名 廢渣檢出器



    RM-1310
    This device will detect the slugs coming up by detecting the displacement of stripper plate when slugs come up. The displacement is detected by the sensors, which are installed on the stripper plate.
    This is the upgrade product of RM-1309S as a simplified model of MX series.
    Monitoring accuracy : +/-1μm
    (RM-1309S monitoring accuracy : +/-5μm)
    Characteristics
    Achieved a low price.
    Quick replacement is achieved by interchangeability of sensor.
    Timing sensor is not required since it has internal synchronization.
    Digital type achieved simple operation. (There is no variation in operator.)
    Detection Method

    The slug, which is caught in upper or lower surface of the raw material will be crashed by stripper plate of the die which has spring loaded stopper at B.D.C. However, 20 to 40% of slug thickness (depends on material) will be remain and it will shift the position of stripper plate. This device will detect the displacement of the stripper plate by comparing with normal position.
    This device will not be affected by the change of material thickness or rise in temperature of the unit since it compares the displacement of the stripper plate at every stroke.
    This device is not be affected by the bound or spring load of the stripper plate due to bottom hold type system which only detects the lowest point of the stripper plate by using micro processor.







    1:大陸地區代理銷售RIKEN的產品,同時負責產品的安裝調試及技術支持;

    2:100%原裝正品;

    3:保修一年終身維修;

    4:價格合理;

    5:詳細技術參數請直接致電公司銷售經理;

    6QQ277899599
