品牌 | 銘海 | 型號 | 860 | 重量 | 30(kg) |
產品介紹
型號/type | 720 | 860 | 960 | 1160 | 1360 | 1660 |
進紙/ paper feed width | 720mm | 850mm | 950mm | 1130mm | 1330mm | 1660mm |
實刻/ Real cutting range | 630mm | 720mm | 800mm | 1000mm | 1200mm | 1500mm |
速度/ Cutting speed | 0~500mm/s | 0~375mm/s | ||||
刀壓/ Cutter pressure | 0~400g | |||||
語言/ Language Form | HP-GL / DMPL compatible | |||||
電源/ Power supply | 220v/110v 50Hz穩壓電壓/Voltage-stabilized source | |||||
緩存/ Buffer | 4M | |||||
支架/ Support | 無/not have | 有/ Existence | ||||
液晶/ Liquid crystal screen | 無/not have | 有/ Existence 中文/English |
·主機板采用雙CPU控製,原裝IC芯片,性能更穩定
·驅動采用高性能步進細分電機,功率大,速度快
·小車刀壓更大,刻小字不變形
·原點定位,急停功能,運行中可調節,時刻為用戶著想
·寬屏中文液晶顯示,操作方便
·超靜音設計,噪音低
·適應各類規格紙張,進紙寬度超過同類機種
·刻繪速度快,曲線刻繪不減速
·可調節式壓輪,保證長距離走紙不走偏,走紙無限長·內置穩壓開關電源,適用電壓范圍寬
1) Forward direction and reverse direction paper feed
2) Emergency stop and free setting original point
3) Maximum speed of 500mm/s
4) Cutter speed and cutter pressure memory and storage
5) Double photoelectric reset and without any collision
6) Perfect output and without any saw tooth at high speed
7) Using the most advance subdivision circuit and having
low noise
8) Using switching power supply and its operation that
isn’t influenced by voltage change
9) Circuit uses low power consumption and doesn’t need
fan for heat radiation so as to ensure long and reliable operation
