聯系人 曹經理 13801200210
本產品在第111屆廣交會中收到瞭外國采購商的大量訂單，場麵空前火爆。
本公司已通過CE認證及ISO9000質量管理體系認證。先進的管理體系和高效的現代化生產方式為產品提供可靠的質量保證。
歡迎廣大國外客戶、外貿公司和施工隊購買！
JHPK-H30型聚氨酯噴塗灌註設備：
1、該型設備已通過CE認證，安全環保。
2、完全自主知識產權設計生產，已申報多項國傢發明專利。
3、平置式增壓泵完美的同軸度結構設計，最大限度的降低瞭密封件的磨損，工作時無壓力差，換向壓力波動值理想穩定；
4、防固化潤滑筒內高速循環的潤滑液可迅速帶走滲漏的原料或雜質，黑料軸始終浸在潤滑液中避免瞭結晶現象。
5、精巧的連軸件結構，使增壓泵便於拆卸維護，必要時還可整體更換單邊原料泵，改變原料配比。
6、氣動換向控製總成，結構簡單、工作可靠，使泵體部分在無電環境下仍可正常工作。
7、停機復位功能的設計應用，實現瞭設備的雙重保護。
8、設備本身高低壓雙重過濾器的設置及噴灌槍自有的過濾器，實現瞭原料通路的三重過濾保護，減少瞭堵槍現象的發生。
9、加熱器內采用特製的鎧裝式溫度傳感器實時采集溫度信號，使加熱過沖值得到瞭良好控製。
10、保溫管路內置的鞭型鎧裝式溫度傳感器，使溫度數據的采集更加靈敏準確，無信號散失。
11、保溫管組采用特殊工藝纏繞專用放熱銅帶，加熱均勻可靠，管路全封閉防水連接並外覆保溫套及耐磨護套，安全耐用。
12、精準的動作計數機方便您收工後準確計算原料的用量。
13、簡潔的控製麵板設置，和設備關鍵部位的操作提示，使您更加快捷的掌握使用。
14、主機架采用實心橡膠輪無需充氣，更適合施工工地的使用。
15、整機完全人性化設計，重量輕、體積小、方便靈活，可收納四組（90米）保溫管組，單人即可實現設備移動。
標準配置：
主機：1臺
噴槍：1把
加熱保溫管路1組：15米（標準配置）
最大長度（可選配）：90米
連槍短管1組：1.5米
供料泵：2支
技術參數
原料配比：1：1標配固定比例(可選配變比)
原料粘度范圍：200～1000CPS（操作溫度下）
原料輸出量：2～7.8Kg/分鐘
加熱溫度范圍：0℃～70℃
電源：三相四線 380V 50HZ 14A×3+16A
氣壓源：0.5～0.8Mpa 1m³/min
單組份原料輸出壓力： 5～10Mpa
裝運參數
設備外型尺寸：930mm×800mm×1210mm
運輸重量 ：125Kg
H30 Polyurethane Spray Perfusion Equipment & PKIII Gun
Our company has obtained Quality Management System Certificates, such as UKAS and ISO9000. The advanced management system and high efficient and modern production mode provide reliable quality assurance for our products.
JHPK-H30 Polyurethane Spray Perfusion Equipment:
1. The equipment has obtained CE certification, safe and environmental protection.
2. Having the proprietary property rights in design and production, several national patents have been applied and approved.
3. The perfect coaxial structure design of the horizontal booster pump reduces greatly the abrasion of the sealing. There is no pressure difference during operation and the commuting pressure fluctuation value is ideal and stable.
4. The lubricant inside the anti-solidifying lubricating cylinder circulates with high speed so that the leaked material and impurities could be brought away rapidly. The shaft for black material is always kept in the lubricant avoiding the crystallization.
5. The delicate coupling structure is easy for the dismounting of the booster pump during the maintenance. When necessary, the completeunilateral raw material pump can be replaced to change the proportion of the raw material.
6. The pneumatic commuting control assembly is simple in structure and reliable in operation, and enables the pump body operating normally during the lack of electricity.
7. The design and application of the reset function when shut down realizes the dual protection.
8. The dual filters of the equipment for both high and low pressure and the filter of the nozzle realize the triple filtration protection for the raw material and reduce the blocking.
9. The special armoured temperature sensor inside the heater can collect the temperature signal at any time, hence the overshooting value for heating is well controlled.
10. The flagelliform armoured temperature sensor inside the heating tube makes the collection of the temperature data more sensitive and accurate without signal losing.
11. The heating tubes adopt special technology for winding the heating copper belt. The heating is even and reliable. The tubes are safe and durable with full closed water-proof connection, as well as the heat insulation layer and anti-abrasion layer.
12. The accurate action counter makes it easy to have the knowledge of material consumption when stop working.
13. The compact control panel and the operation hint of key parts make it easy for fast handling and operation.
14. The equipment frame uses the solid rubber wheel dispensing with air filling which is more suitable for the construction site.
15. The equipment is of humanization design with low weight, small volume. It is convenient and flexible and can contain 4 groups of heating tubes (90 meters). It can be easily shifted by one person.
Standard Configuration:
Main equipment: 1 set
Nozzle: 1 pc
Heating tube per group: 15 meter (standard)
Max. length (optional): 90 meter
Short tube with nozzle per group: 1.5 meter
Feeding pump: 2 sets
Technical data:
Proportion of raw material: 1:1 standard fixed ratio (changeable ratio can be selected)
Viscosity range of raw material: 200-1000 CPS (under operation temperature)
Output of raw material: 2-7.8 kg/min
Heating temperature range: 0℃～70℃
Electrical source: 3 phase 4 wire, 380V 50HZ 14A×3+16A
Compressed air: 0.5～0.8Mpa 1m³/min
Output pressure of raw material per group: 5～10Mpa
Dimension: 930mm×800mm×1210mm
Weight: 125Kg
