WM精密測量規和薄墊片是目前精密墊片行業中規格最齊全供應商
超過500餘種的貨物庫存
通過和客戶的緊密聯系,我們得到瞭客戶需求產品的第一手資料。因此我們的庫存提供瞭厚度從0.005到0.30mm的多種非標準不銹鋼產品。我們還提供厚度從1.00到3.0 mm的硬質不銹鋼1.4034。Wemar以下列方式提供厚度從0.003mm到4.0mm的60餘種不同產品。
間隔0.005mm直到0.06mm
間隔0.01mm直到0.30mm
間隔0.05mm直到1.00mm
間隔0.10mm直到2.00mm
附加提供2.50;3.00和4.00mm厚度(還可根據需求提供3.50mm厚度)
More than 500 products available from stock
A close contact to our customers gives us an insight into their needs. As a result we stock now many non-standard thickness between 1.00 and 3.0mm in stainless steel AISI 301.We also offer hardened stainless steel 1.4034 in thicknesses between 1.00 and 3.0mm.WM suplies more than 60 different thicknesses from 0.003mm and 4.0mm in the following manner:
Up to 0.06mm in steps of 0.005mm
Up to 0.03mm in steps of 0.01mm
Up to1.00mm in steps of 0.05mm
Up to 2.00mm in steps of 1.10mm
Additionally 2.50;3.00;and 4.00mm(3.50mm upon request)
Hardened and tempered High Carbon Steel 1.1274
Due to a carbon content fo more than 1% this alloy is ideal for feeler gauges stock, shims and springs wher corrosion
problems are not expected. This material is magnetic. Available in thickness between 0.01 and 2.0mm.
高碳鋼1.1274
由於含碳量高於1%，並且有較好的耐腐蝕性，所以這種磁性材質是生產量規和墊片的理想原料。可提供0.01到2.0mm不同厚度的標準產品。
Hardened and tempered tool steel 1.2003
A small amount of Chromium leads to a higher wear resistance and better hardening for large widths. This alloy is also
suitable for small tools due to aRockwell hardness of 47-51 HRC. This magnetic alloy is our standard Carbon steel for thickness
between 1.0 and 4.0mm.
工具鋼1.2003
當寬度較大時，少量的鉻元素可增加材質的耐性和硬度。這種合金材質的硬度可達到洛氏硬度47-51HRC，適用於製造小工具，可提供1.0到4.0mm不
同厚度的標準產品。
Hardened and temprerd Stainless Tool Steel 1.4034(1.2083)
This Steel is corrosion resistant at wet air,steam and water,but not resistant against chloride irons and acids Compared to 1.4310(AISI301)this
alloy has a lower corrosion resistace. This alloy has advantages in better wear resiastance and low inner stress. It is ideal for gages,tools, machine
knifes in the food industry and scalpels. The alloys 1.4034 and 1.2083 have little differences in the carbon content.This alloy is magnetic.Available in
thicknesses between 1.0and3.0mm.
工具鋼1.4034（1.2083）
這種鋼抗潮濕,但不能抵抗氯及酸性物質的腐蝕。比1.4310（AISI301）這種材質的耐腐蝕性要差一些。
這種材質的優點在於它的耐磨性和低內應力，適於食品工業的表、刀具及解剖的製造。1.4310這種磁性材質和1.2083僅在含炭量上存在微小的差
別。可提供1.0到3.0mm的不同厚度。
Temper rolled Stainless steel 1.4310
This Steel has a good corrosion resistance due to a content of 17% Chro mium and 7% Nickel. Ahigh tensile strength is obtained by cold rollingCompared to Alloy 1.4301(AISI304) a much higher tensile strength of more than 2000N/mm can not be reached. Because of this, 1.4310 is suitable for stainless feeler gage stock, precision foils, stainless springs and parts of higher strength, This alloy is little magnetic and can not be hold by magnetic tablesof grinding machines. Available in more than 60 thickness between 0.003 and 3.0mm.
回火冷軋不銹鋼1.4310
這種材質由於含有17%的鉻和7%的鎳，所以具備較強的抗腐性。這種材質通過冷軋來實現較高的抗拉強度比1.4301(AISI304)具備更高的抗拉強度可達到2000N/mm。正是由於這種較強抗拉強度，使得它適於製造不銹鋼間隙測量規，精密墊片，不銹鋼彈簧和高彈性零部件。這種材質的磁性較弱，不能吸附在磨床的磁性工作臺上。可提供從0.003到3.0mm60餘種不同的厚度。
Temper rolled Brass 2.0321
With a composition of 63% copper and 37% Zinc this Brass is the standard alloy for temper rolled brass. It is not magnetic.
Avaiable from 0.01 to 1.00mm.
回火冷軋銅2.0321
這種回火冷軋銅(非磁性材質)含有63%的銅和37%的鋅。
提供0.01到1.00的不同厚度。
We can also supply Carbon steels like CK 75 (1.1248) as well as Stainless Steels like 1.4310(AISI 304)and 1.4404(aisi316L).
Please ask for availability and Price if you need these or similar alloys.
我們不但能提供像CK75（1.1248）這樣的碳鋼，還可以提供像1.4310(AISI 316L)和1.4404(AISI 316L)這樣的不銹鋼。
如果您需要這樣的產品或類似產品，歡迎隨時詢問！
質量檢驗Quality inspection
Rolled to precise thickness tolerances
The thickness tolerances of WM precision shim foils meet the international Standard T 3(Stainless steel with a width of 12.7 and 600 mm are according to DIN EN 10258). These tolerances are even closer than required by BIN 1544 /DIN EN 10140.The technical information table gives information on absolute permissible deviation on thickness.
During manufacturing continuous inspection ensures our close tolerances are met.
Product information and product batch are marked on the WM label. The material can be traced back to the cast. In addition most strips are marked with thickness and production batch.
With this information we can send you a certificate 2.2 B according to DIN EN 10 240 even if you already have the products for a fee of 5,20 Euro per certificate.
精確的厚度公差
WM精密間隙測量規和薄墊片的厚度公差符合國際標準T3（不銹鋼帶的寬度為12.7和600毫米符合DIN EN 258）這些公差接近甚至比15441標準DIN EN10140更高的標準要求我們提供的技術資料表上有更祥盡的厚度精密標準信息。
在製造過程中不斷地進行檢驗，確保我們的緊密公差得到滿足
平整度Flatness
WM經過硬化處理的WM精密帶鋼，其平整度在各種機械零件中成為重要的參數。 的生產過程確保所有的最終產品具有精確的平整度。
WM The flatness of hardened WM precision strip steel is an important parameter in the production of many different types of machine parts.The production process at WM ensures the correct flatness for the large variety of end products.
厚度公差Thickness tolerances
WM生產的精密鋼厚度公差可達到最高國際標準。公差級別為T1到T5，包含所有邊緣處理。下表為不同公差等級的參數值。
WM achieves thickness tolerances for precision strip steel which meet the highest international standards, The tolerance classes, T1 to T5,are applicable for all of our precision strip regardless of the edge finesh. The numerical data for the different tolerance classes are contained in the following table.
寬度公差Width tolerances
我們製造的冷軋精密鋼符合瑞典公差等級B1到B3：
We manufacture cold-rolled precision strip steel according
to the Swedish tolerance groups B1 to B3:
