性能參數Technical Specifications
性能指標 Performance Paraeter Performance 機型Model |
JC-6060 |
XYZ軸運動定位精度 X Y Z axis movement pointing accuracy |
±0.01/300mm |
XYZ軸重復定位精度 X Y Z axis redundant pointing accuracy | meishene ±0.015mm |
分辨率 Resolution |
±0.015mm |
XYZ軸工作行程 X Y Z axis power stroke |
600*600*150mm |
工作平臺尺寸 Working platform size |
700×1120mm |
主軸功率 Main axle power | 1500W無刷水冷、變頻調速 1500Wbrusheless water cooled spindle with frequency inverter |
最高速度 Maximum speed |
6m/min |
電源要求 Power source request |
AC220V±10% |
刀具直徑 Cutting tool diameter |
♂3.175♂4♂6♂8mm |
雕刻指令 Carving instruction |
G代碼★.u00★.mmg★.nc. |
功率（不含主軸） The power (does not contain main axle) |
300W |
數據接受方式 The data accepts the way |
PCI |
重量 Weight |
240kg |
工作方式 Working |
步進Steper |
雕石材另配水槽。
註：參數、圖片如有變動恕不另行通知。
Note: The parameter, pictures are subject to change without notice
性能特點：Performance Features
★配德國產雙螺母滾珠絲桿，進口導軌。
★采用斷點記憶方式，保證可在意外（斷刀）或隔天情況下加工。
★獨特的多個工件原點的保存方式。
★龍門式移動，堅固耐用長時間使用不變形，使定位精度更加精確。
★大功率切削不僅使雕刻精細無鋸齒，底麵平整光滑輪廓清晰，進行2公分有機也輕松自如。
★本機非常適合建築模型、標志業、學校、企業事業單位使用。
★The CNC router adopts the mode of saving the intermittence.
★Memory to insure the processing point when the blade is broken or postpone situation
★Specific saving mode of different points
★The Dragon Gate type migration, the firm durable long time use does not distort, causes the pointing accuracy to be more precise.
★The high efficiency cutting not only causes the carving not to have the denticle fine, the bottom surface smooth smooth outline is clear, carries on 2 centimeters organically also relaxed freely
★This aircraft is suitable to construct the model, the sign industry, the school, the Business and enterprise unit to use.
使用范圍：
廣告行業：雕刻、切割各類標牌、座標牌、。
工藝品行業：工藝品、紀念品上刻各類文字、圖形。
模具加工業：用於模具業中精細文字和花紋的雕刻和小型模具產品的加工。
建築模型業：雕刻一些精細的小窗戶、圍欄、墻飾花紋等一些細小模型。
印章行業：可在牛角、塑料、有機、木頭、儲墨墊等材料上方便的刻製各類印章。
Use scope:
Advertisement profession: The carving, cuts each kind of product label, to sit the product label.Handicraft profession: On the handicraft, the souvenir engraves each kind of writing, the graph.Mold processing industry: Uses in the mold industry fine writing and the pattern carving and the small mold product processing.
Construction model industry: Carves some fine small windows, the railing, the wall to play the part of the pattern and so on some tiny models.
Seal profession: May cutting each kind of seal which in the buffalo and cow horns, the plastic, organic, the wood, materials and so in Chu Modian facilitates.
適用材質：
銅、鋁質材之上製作精美的徽章和獎牌，或是在玉石、雙色板、塑料板、PVC板、壓克力、木材、密度。
Is suitable the material quality:
Copper, above the aluminum nature material manufactures the fine badge and the medal, perhaps in jade, double color plate, plastic film, PVC board, acrylic fabric, lumber, density board
歡迎來電詳談！！
