    廣告雕刻機 電腦雕刻機 木工雕刻機 立體雕刻機 cnc雕刻機GT-6090
    商品代碼: 487913
    (可點擊以下立即詢價直接線上諮詢,或來電提供此商品代碼諮詢)
    即日起提供日本樂天代購服務-詳見 Rakuten-suki日本樂天代購,謝謝。
    商品詳細說明
    產品介紹:
    應用行業/Applicable Industry
    適用於:廣告標牌標識業、建築模型、電子電器、學校、企事業單位等。可加工材質:有機玻璃、雙色板、鋁塑板、塑料、木材、ABS、PVC、MDF、PCB、銅、鋁等材質
    Suitable for industries such as billboards, model industry, electronics and electic appliances, schools companies and governments. Available materials: acrylic, double color boards, plastic, wood, ABS, PVC, MDF, PCB, copper, aluminium and various non-ferrous metals
    產品描述/Technical Parameter
    1、整體鑄造床身, 結構合理, 回火處理和二次精密加工,有效保證床體堅實耐用
    2、采用恒功率水冷變頻電機, 性能好, 力矩大, 噪音小
    3、系統智能控制加工速度、空程速度和落刀速度,提高加工效率,延長刀具受命
    4、采用對斷電、斷刀、斷點記憶加工方式,保證在意外情況下可繼續加工, 解決客戶後顧之憂
    1、GTseries adopt overall iron casting machine body, rational structure, through special tempering and twice precision processing to ensure more durable and solid
    2、GTseries furnish with famous brand inverter-driven constant power spindle motor cooled by water,good performance, big strength and high efficiency
    技術參數/Technical Parameter
    GT-6090 技術參數
     產品型號/Model
     GT-6090
     工作行程/Working area
     600*900*100mm
     外觀尺寸/Volume

     主軸功率/Main axle power rate
     1.5/2.2KW(可選)
     主軸轉速/Main axle rotating speed
     6000-24000 rpm/min
     最大加工速度/Max.Working speed
     0-5000mm/min
     最大進料高度/Feeding height
     100mm
     刀柄直徑/Engraving tools
     3.175/4/6mm
     重復定位精度/Repositioning Accuracy
     0.01mm
     文件格式/Supported File Forma
     DXF,PLT,G代碼,mmg,u00,nc
     工作電壓/Power
     AC220V/50HZ      AC110V/60HZ(可選)
     整機重量/Weigth
     200kg
