HS系列臥式恒溫培養搖床HS Series horizontalLarge-capacity Constant Temperature Shaking Incubator
一.用途概述:
HS臥式搖床是專為現代生物工程生產單位研製開發的一款大容量恒溫培養製取設備。HS-211B/111B是標準型，最大裝瓶規格為1000ml；HS-211C/111C是加高型,最大裝瓶規格為5000ml機器廣泛應用於對溫度、振蕩頻率有著較高要求的細菌培養、發酵、雜交和生物化學反應以及酶、細胞組織研究等。在醫學、生物學、分子學、製藥、食品、環保等研究應用領域有著廣泛而重要的應用。
二、產品特點：
智能化聲光報警環境掃描微處理控製器LCD大屏幕背光液晶顯示屏顯示各設定參數和實測參數
運行參數加密鎖定，避免人為誤操作運行參數記憶功能，避免繁瑣操作
定時設定長達999小時，終點自動停止振蕩並聲光報警
交流感應長壽命電機設計，寬調速、恒力矩、恒轉速、無碳刷、免保養
超溫聲光報警功能，電機過熱、溫度失控、異常超溫機器自動切斷各自供電
具有斷電恢復功能，在外電源突然失電又重新來電後，設備可自動按原設定程序恢復運行
控製加速的線路確保搖床緩緩啟動、平穩加速，保證實驗樣品的安全
極富美學設計理念的流線型豪華整機造型，靜電噴塑箱體，大屏幕鋼化玻璃視窗
Summary
HS horizontal shaking incubator, particularly developed for modern biological engineering companies, HS-211B/111B is the standard mode; max bottle size up to 1000ml. HS-211C/111C is the heightened mode, max bottle size up to 5000ml. The HS horizontal shaking incubator is widely used in germ culture, ferment, hybridization, and research of biochemical reaction, enzyme and cellular tissue and all those require high temperature and oscillation frequency. It has a wide and important range of applications in research of medicine, biology, numerator, pharmacy and environmental protection.
Features
1.P.I.D environmental scanning micro-processing controller and intelligentized audio and visual alarm2.The large LCD screen clearly indicates the preset and real parameters.
3.The operating parameter locked by encryption prevents misoperation.4.Operating parameter memory function avoids monotonous operations
5.Timer up to 999 hours and audio and visual alarm will be activated when shaking terminates.
6.AC inductive long-life motor design, broad speed regulation, constant torque, constant speed of rotation, no carbon brush and maintenance free.
7.Over-temperature audio and visual alarming function can automatically cut off the power when the motor overheated, temperature out of control or abnormal temperature occurs.
8.Provided with power-off recovery function, the equipment can automatically recover to run according to the originally designed programs when the external power is recovered after a sudden cut off.
9.Wiring of the acceleration control ensures soft start, smooth acceleration and the security of samples.
10.The luxurious streamline mould involving aesthetic designing, static plastic-spraying case and large toughened glass window.
三．技術參數。(Specifications):
產品型號Model | HS-211B | HS-111B | HS-211C | HS-111C |
旋轉頻率范圍Speed Range | 60∽300rpm | |||
頻率精度Speed Precision | ±1rpm | |||
擺振幅度Oscillation Amplitude | Φ26mm | |||
最大容量Maximum Capacity | 250ml×36 or 500ml×28 or 1000ml×18 | 500mL×28 、 1000mL×18 、 2000mL×8 、 3000mL×8 、 5000mL×6 | ||
標準配置Standard Configuration | 500ml×28 | 8×2000ml | ||
托盤尺寸Tray Dimension | 920×550(mm) | 920×500(mm) | ||
定時范圍Time Range | 0—999小時（Hour） | |||
溫控范圍Temperature Range | 4-60℃ | RT+5℃-60℃ | 4-60℃ | RT+5℃-60℃ |
溫度波動Temp. Control Precision | ±0.5℃（恒溫狀態）（Homoeothermic） | |||
溫度均勻度Temperature Uniformity | ±1℃ | |||
數顯方式Display | LCD | |||
托盤數量Tray Number | 1Pcs (accessories available) | |||
外型尺寸Exterior Dimension | 1200×740×800(mm) | 1200×740×1000(mm) | ||
包裝尺寸Packing Dimension | 1320×830×1000(mm) | 1320×830×1150(mm) | ||
凈重Net Weight | 174kg | 160kg | 183kg | 168kg |
容積Capacity | 970×565×280(mm)(155L) | 970×565×480(mm)(265L) | ||
消耗功率Consumption Power | 866W | 570W | 951W | 676W |
電源Voltage | AC 220V±10% 50∽60HZ | |||
