◆產品介紹：
HPC802型除集HPC801全部功能外，還可檢測目前電噴類汽車發動機的故障碼及故障，其包括歐洲車系、美洲車系、日本車系、韓國車系、中國車系、OBD II介面車系，該機器功能強大、操作簡單，以計算機為平臺，配有打印機可打印檢測結果，人機對話界麵友好、升級方便快捷、集成、汽車故障測試、汽車詞典、汽車檔案管理等多種功能。
◆In addition HPC801, HPC802 full functionality can be extended EFI category
of the current car engine fault and the fault code, including the European car
lines, the Inter American car, truck of Japanese, Korean car line, the Chinese
car line, OBD II interface of the car, the equipment is powerful, simple operation,
the computer as a platform, equipped with printers can print test results, the man machine dialogue friendly interface, upgrades convenient, integrated, automobile
fault testing, automotive dictionary, automotive File Management , and other functions.
◆ 技術參數：
無負載測功檢測線聯網功能，電噴車故障解碼，充電電壓電流檢測，車載傳感器波形分析，汽車水溫、油溫測量，進氣岐管真空度值及波形分析，汽車異響配氣相位及波形分析，啟動電壓電流，汽缸壓力及波形分析，柴油車噴油壓力，提前角及波形分析，點火提前角、重疊角、點火高壓及波形分析。
◆No load dynamometer testing line networking capabilities EFI cars fault detection decoding
charging voltage and current waveform analysis automotive vehicle sensor temperature, oil
temperature measurement intake manifold vacuum of values and abnormal sound waveform
analysis with cars and gas phase voltage and current waveform analysis activated , and
cylinder pressure waveform analysis diesel vehicles injection pressure, advance angle and
waveform analysis ignition advance angle, overlap angle, high voltage and waveform analysis
ignition
| 測試范圍The scope of testing | 精確度(FS)Precision (FS) | 備註remerks |
發動機轉速engine speed | 100-7200rpm | ≤±1% |
|
起動電流/充電電流starting current / charge current | 50-500A/10-50A | ≤±5% |
|
起動電壓/充電電壓starter voltage / charge voltage | 0-30V | ≤±2% |
|
氣缸壓力 Cylinder Pressure | 0-4Mpa | ≤±5% |
|
柴油供油壓力diesel oil supply pressure | 0-60Mpa | ≤±5% |
|
點火提前角ignition advance angle | 0-50° | ≤±1% | cam angle |
配氣相位Valve Timing | 0-360° | ≤±1% |
|
分電器重疊角electrical overlap angle | 0-25° | ≤±1% |
|
白金閉合角platinum closed angle | 0-90° | ≤±5% | cam angle |
點火高壓ignition hyperbaric | 0-40KV | ≤±1% |
|
回事時間matter of time | 200-2000ms | ≤±5% |
|
無外載測功 Dynamometer | 0-500KW | ≤±5% |
|
異響振動abnormal sound vibration | 1-5000Hz 0-100g | ≤±5% |
|
進氣管真空度intake manifold vacuum | 0-100Kpa | ≤±5% |
|
溫度計thermometer | (-50-150) ℃ | ≤±1% |
|
煙度/尾氣Smoke / exhaust gas |
| ≤±1% | optional pieces |
解碼器decoder |
|
| optional pieces |
