Excellent Anti-abrasion
Longer Service Life
High-Strength, Low-elongation Material: High tenacity polypropylene fiber Specific Gravity: 0.94 (Float) Melting point: 165°C Water Absorption: None UV light resistance: Good Abrasion Resistance: Good Eye Splice: Good SuperLine 8 S/T | | DIA | CIR | WT | B/S | | MM | INCH | INCH | KGS/100M | LBS/100FT | LBS/100FM | Kg | kN | | 24 | 15/16 | 3 | 28.8 | 19.4 | 116.1 | 12,000 | 117.7 | | 28 | 1-1/8 | 3-1/2 | 39.4 | 26.5 | 158.9 | 16,000 | 157.0 | | 32 | 1-1/4 | 4 | 51.1 | 34.3 | 206.0 | 20,300 | 199.1 | | 36 | 1-7/16 | 4-1/2 | 64.1 | 43.1 | 258.4 | 25,300 | 248.2 | | 40 | 1-9/16 | 5 | 79.1 | 53.2 | 318.9 | 31,200 | 306.1 | | 44 | 1-3/4 | 5-1/2 | 97.7 | 65.7 | 393.9 | 37,800 | 370.8 | | 45 | 1-25/32 | 5-5/8 | 102.0 | 68.5 | 411.2 | 39,400 | 386.5 | | 48 | 1-7/8 | 6 | 114.5 | 76.9 | 461.6 | 43,800 | 429.7 | | 50 | 2 | 6-1/4 | 124.5 | 83.7 | 502.0 | 47,600 | 466.9 | | 52 | 2-1/16 | 6-1/2 | 134.0 | 90.0 | 540.3 | 50,800 | 498.3 | | 55 | 2-5/32 | 6-7/8 | 150.5 | 101.1 | 606.8 | 57,000 | 559.2 | | 56 | 2-1/4 | 7 | 156.0 | 104.8 | 629.0 | 58,500 | 573.9 | | 60 | 2-3/8 | 7-1/2 | 179.0 | 120.3 | 721.7 | 66,600 | 653.3 | | 64 | 2-1/2 | 8 | 203.6 | 136.8 | 820.9 | 74,800 | 733.8 | | 65 | 2-9/16 | 8-1/16 | 210.0 | 141.1 | 846.7 | 77,000 | 755.3 | | 68 | 2-11/16 | 8-1/2 | 230.0 | 154.6 | 927.3 | 83,800 | 822.1 | | 70 | 2-3/4 | 8-11/16 | 243.5 | 163.6 | 981.8 | 88,700 | 870.1 | | 72 | 2-7/8 | 9 | 258.0 | 173.4 | 1,040.2 | 94,000 | 922.1 | | 75 | 3 | 9-1/4 | 279.5 | 187.8 | 1,126.9 | 101,800 | 998.6 | | 80 | 3-5/32 | 10 | 319.0 | 214.4 | 1,286.2 | 116,000 | 1,137.9 | | 85 | 3-3/8 | 10-1/2 | 360.5 | 242.2 | 1,453.5 | 131,000 | 1,285.1 | | 88 | 3-7/16 | 11 | 386.0 | 259.4 | 1,556.3 | 138,000 | 1,353.7 | | 90 | 3-9/16 | 11-1/8 | 403.5 | 271.1 | 1,626.8 | 144,000 | 1,412.6 | | 95 | 3-3/4 | 11-3/4 | 449.5 | 302.1 | 1,812.3 | 160,000 | 1,569.6 | | 96 | 3-13/16 | 12 | 459.0 | 308.4 | 1,850.6 | 163,000 | 1,599.0 | | 100 | 3-15/16 | 12-3/8 | 498.0 | 334.6 | 2,007.9 | 176,000 | 1,726.5 | | 104 | 4-1/8 | 13 | 536.0 | 360.2 | 2,161.1 | 187,000 | 1,834.4 | | 112 | 4-7/16 | 14 | 623.0 | 418.6 | 2,511.8 | 215,000 | 2,109.1 | | 120 | 4-3/4 | 15 | 718.0 | 482.5 | 2,894.9 | 246,000 | 2,413.2 |
| Manufactured and tested according to ISO and JLQW standards.
* Warning : The min. breaking strength should never be considered as the safe working load of the rope |
| | | ![]() SuperLine 12 S/T | | DIA | CIR | WT | B/S | | MM | INCH | INCH | KGS/100M | LBS/100FT | LBS/100FM | Kg | kN | | 36 | 1-7/16 | 4-1/2 | 64.1 | 43.1 | 258.4 | 26,600 | 260.9 | | 40 | 1-9/16 | 5 | 79.1 | 53.2 | 318.9 | 32,700 | 320.8 | | 44 | 1-3/4 | 5-1/2 | 97.7 | 65.7 | 393.9 | 39,700 | 389.4 | | 48 | 1-7/8 | 6 | 114.5 | 76.9 | 461.6 | 46,000 | 451.2 | | 52 | 2-1/16 | 6-1/2 | 134.0 | 90.0 | 540.3 | 53,300 | 522.9 | | 56 | 2-1/4 | 7 | 156.0 | 104.8 | 629.0 | 61,500 | 603.3 | | 60 | 2-3/8 | 7-1/2 | 179.0 | 120.3 | 721.7 | 70,000 | 686.7 | | 64 | 2-1/2 | 8 | 203.6 | 136.8 | 820.9 | 78,600 | 771.0 | | 68 | 2-11/16 | 8-1/2 | 230.0 | 154.6 | 927.3 | 88,000 | 863.3 | | 72 | 2-7/8 | 9 | 258.0 | 173.4 | 1,040.2 | 98,700 | 968.2 | | 80 | 3-5/32 | 10 | 319.0 | 214.4 | 1,286.2 | 121,800 | 1,194.8 | | 88 | 3-7/16 | 11 | 386.0 | 259.4 | 1,556.3 | 144,900 | 1,421.4 | | 96 | 3-13/16 | 12 | 459.0 | 308.4 | 1,850.6 | 171,000 | 1,677.5 | | 104 | 4-1/8 | 13 | 536.0 | 360.2 | 2,161.1 | 197,000 | 1,932.5 | | 112 | 4-7/16 | 14 | 623.0 | 418.6 | 2,511.8 | 226,000 | 2,217.0 | | 120 | 4-3/4 | 15 | 718.0 | 482.5 | 2,894.9 | 259,000 | 2,540.7 |
|
| | | | |
| | | | |
|
