供應高質量EATON計數器，型號: E5-648-C2421，特惠價，交期迅速，歡迎來電垂詢！
主要參數:
| Item | Counter | |
| Type | 1/16 DIN, 2 Presets, 2 Outputs | |
| Number of Digits | 6 | |
| Display | 2 Line Backlit LCD | |
| Counts | 2 | |
| Counts per Second | 55kHZ | |
| Input Signal | PNP/NPN | |
| Input Voltage | 90-260VAC | |
| Output Rating | 3A @ 250VAC, 3A @ 110VDC | |
| Mounting | Panel | |
| Length | 1.89" | |
| Depth | 3.58" | |
| Width | 1.89" | |
| Relay | 2 | |
| Series | E5 | |
| Scaler | Yes | |
| Preset | 2 | |
| Min. On/Off Pulse | 10ms | |
| Power Rating | 8VA | |
| Prescaling Range | 0-0001-99.999 | |
| Reset Type | Front / Rear | |
| Special Features | Programmable As Preset Counter, Batch Counter Or Totalizer. Preset Counters Function As Timer Or Tachomter/Ratemeter. Direct Input Of Presets Via Front Keys Or Teach-In Inputs. Relay Outputs. |
