HF-R1200 Multifunction Arc polishing machine
多功能圓弧拋光組合機
HF-R1200型14組多功能圓弧拋光組合機是我廠自主研發生產的最新型陶瓷、石材深加工設備，適用於陶瓷、大理石,花崗巖等不同材料。該設備集圓弧拋光機、藝術線條機的功能於一體，可以加工樓梯踏步.地腳線.梯級磚.L型.45度.圓弧邊.防滑槽拋光等陶瓷.石材瓷磚加工，具有操作簡便、加工速度快、功能齊全、計量上乘等特點。是繼圓弧拋光機之後的一大新興產品。自投放市場以來，受到廣大客戶的一致好評。
HF-R1200 Multifunction Arc polishing machine is our latest develop product for ceramic,marble,granite,This machine combined Arc Polishing machine and Profiling machine,it is suitable for step tile,L type,skirting,45°edge,polishing the groove of tile.After the machine introducing in the market,is speak highly by clients.
型號 | Description | 單位/Unit | HF-R14 |
輸送帶數量 | Qty of conveying belt | pcs | 1 |
拋光磨頭數量（圓弧） | Qty of polishing heads | pcs | 14 |
拋光磨頭直徑 | Dia of polishing head | mm | Φ100 |
倒角磨邊輪數量 | Numbers of chamfering wheel | pcs | 5 |
倒角磨邊輪直徑 | Dia of chamfering wheel | mm | Φ150 |
定型輪直徑 | Dia of shaping wheel | mm | Φ150 |
定型輪數量 | Qty of shaping wheel | pcs | 2 |
拋光輪數量 | Qty of polishing wheel | pcs | 4 |
拋光輪直徑 | Dia of polishing wheel | mm | Φ150 |
氣動倒邊角磨頭數量 | Qty of down chamfering head | 個/pc | 1 |
氣動倒邊角磨頭直徑 | Dia of down chamfering head | mm | Φ100 |
吹乾出風口 | Qty of drying meatus | 個/pc | 2 |
工作寬度 | Working width | mm | 80-1000 |
拋光速度 | Polishing speed | m/min | 1.5-7.5 |
加工磚厚度 | Working thickness | mm | 6-30 |
總功率 | Total power | kw | 47 |
耗氣量 | Air consumption | L/min | 55 |
外型尺寸 | Dimension | m×m×m | 10.5×2.3×1.8 |
重量 | Weight | kg | 8000 |
