1 全自動數控中空玻璃生產線（可生產LOW-E中空玻璃）。
2 整機采用PLC控製設備運轉觸摸屏人機界麵，板壓段具有電路、氣路自動診斷功能。
3 采用進口真空發生器和吸盤，玻璃吸合效果更佳。
4 可生產二層、三層、大小片等異型中空玻璃。
5 全距離自動變頻調速，節省勞動等待時間，提高生產效率。
6 玻璃合片時平壓機前後箱機械手杠桿式托料，(機械式硬限位＋活動板吸盤吸附)
   確保自動合片時玻璃永不錯位。

Brief Introduction

• It is a completely automatic insulating glass production line (can produce LOW-E Insulating glass).
• Then entire machine adopts the PLC controls the working condition.
• Adopts the imported vacuum generator and sucker, the suction effect to the glass could be much better.
• bases the customers¡¯ different request, the entire machine can be improved and produce the Step IG Unit and three Piece IG production.
• Full distance automatic changeable frequency speed adjustment, which can save work waiting time and improve production efficiency.
• When glass is pressed, the front and back part of flat pressing machine willup the glass with lever- type arm and hand system,( mechanical position + mobile sucking system) all this will ensure no malposition.

技術參數Technical Parameter
輸入電源 Input voltage                     380V 50Hz
輸入功率   Input power                    19.5Kw

最大加工尺寸  Minimum processing size    1800×2500mm
最小加工尺寸Minimum processing size      280×400mm
原片玻璃厚度 Glass thickness                    3~18mm
傳送速度 Travel speed                              8~45m/min
外形尺寸Overall dimensions     16000×2350×2680mm

總重量 The total  weight                5500kg
