ty8325玻璃直線磨邊機適用於磨削不同尺寸和厚度的平板玻璃的直邊、倒棱。直邊的粗磨、精磨、拋光及兩邊棱角的粗磨、精磨一次完成。該機選用機械無級調速電機，調速范圍大，變速平穩，可在磨削過程中改變磨削速度及送料速度，履帶式橡膠壓板，夾緊並傳動厚度3-25毫米的玻璃進行磨削。精磨砂輪選用金剛石磨輪，磨削鋒利。精磨砂輪選用樹脂，加工精度高，用羊毛氈輪加氧化鈰拋光劑拋光，表麵光潔度，經過磨削的玻璃表麵可達鏡麵光潔度。
主要技術參數：
1、進料速度：0.5-6.5m/min
2、直邊最大磨削量：4mm
3、棱角角度：45°
4、玻璃板最小尺寸：60×60mm
5、玻璃板厚度：3-25mm
6、總功率：17kw
7、外形尺寸：7000×1300×2500mm
8、重量：3300kg
9、電壓：380V 50Hz

8 wheels glass Edgers
ty8325 Glass Straight-Line Machine:The machine is applicable to the grinding edge,botton edge and pointedness of plate glass of different size thickness.It provides rough and fine gringing and polishing at once.It can be polishing itself,and the edge that has been polished just looks like the origenal.While adjusting different processing thickness,collate the transmitting systen that controled by eletronic before adjusting,and the fore chamfering grinder can be moved synchronically with the fore beam,with advanced structure high precision,easy operation and high working efficiency.It is the necessary tool fpr glass technology.

Power(W): 17.25kw
Dimension(L*W*H): 7000*1000*2500mm
Weight: 2800kg
thickness: 3mm-25mm
Min.glass size: 80mm*80mm .
Warranty: half a year After-sales Service Provided: Overseas third-party support available Glass
