通用最新檢測機MDI
MDI--是美國通用提供給特約維修站使用的第三代檢測機，2009年前後的通用的大部分車型，是通用汽車全球服務站必備產品.
MDI是美國公司針對GM裝備有多路傳輸系統(4 GMLINE)的新車型提供電子故障診斷和維修編程的專用維修設備，該系統需配合PC機使用。目前隻能檢測部分GM新車型，老車型還需用TECH2進行檢測。MDI可對所有GM車型進行編程，且編程速度比TECH-2有很大提高。
GM MDI是連接在車輛和電及之間、用於診斷和重新編程的一種特殊工具。通過MDI用戶可以接入到TIS2 Web做維修編程、通過MDI用戶可以使用KDR軟件對車輛進行診斷將來，電腦MDI將會逐步代替目前Tech2的功能，成為維修技術師與車輛交互的界麵。
MDI的應用特點：
具有USB連接；
可實現一臺電腦安裝兩個以上的MDI；
功能強大的TIS2 WEB遠程服務器支持，在線下載編程數據與升級軟件；
診斷數據可隨意保存於個人電腦中，便於製作診斷數據檔案；
可在任何安裝瞭Windows XP的個人電腦上運行使用；
MDI模塊功能：
1.GDS2原廠軟件，具有強大的和全麵的檢測功能，測試動力系統，車身和底盤
2.支持2009年後的所有通用車系，包括北美通用，上海通用，凱迪拉克，saab薩博,GMC,等車型
3.支持有線網路和USB連接
4.2000-2012年支持Pass-Thru方式的維修編程
5.2009年之後支持車輛診斷和在線編程
6.縮短維修編程時間,GMLAN通訊協議的ECU編程時間為目前使用Tech2的1/3
7.可以對新君威，新君越，科魯茲，英朗,GL8 MPV車型節氣門學習(08年-09的君越也可以進行節氣門學習）
8.可以在線匹配新君威，新君越，科魯茲，英朗車型鑰匙（增加或是全丟都可以，不用拆解BCM）
9.可以對1999-2009年之間的大多車型在線編程。包括發動機，變速箱等電腦
Multiple Diagnostic Interface
Description:
GM MDI (Multiple Diagnostic Interface) for wireless ECU reprogramming utilizing J2534. Hardware kit only.
The GM MDI is initially being introduced with Pass-Thruprogramming capabilities only. It can be used to perform
Pass-Thru programming on all vehicles built since 1993 and willsupport all vehicles into the future.The GM MDI will
be required to perform diagnostics onseleced NAO vehicles for model year 2009. Diagnostic soft-ware is scheduled to
be released for the GM MDI during thefourth quarter of 2008.
When diagnostics are introduced, the MDI will also get a remote data record capability. This permits recording data
duringa road test, similar to the Tech 2 Snap Shot function. A trigger switch connector is provided for this
purpose. Regulations require programming procedures to be compliantwith SAE Recommended Practice J2534. The GM SPS
is com-pliant with SAE Recommended Practice J2534, and the GMMDI is compliant with the portions of SAE J2534 that
areapplicable for GM vehicles.
The Future of the Tech 2
The Tech 2 remains an essential tool through at least the 2010 model year. The GM MDI will not support past models
when its diagnostic capabilities are introduced. And, the Tech2 will continue to be needed to diagnose all vehicles
fromprevious model years. Remote programming with the Tech 2 will continue to be supported for use on all 2007 and
previous vehicles.Additional information will be supplied in future.
Introduction of MDI
The GM MDI is a compact communication module that manages the transfer of data between a vehicle’s onboard
ECU network and a PC.The EL-47955 MDI is a kit of components:
A GM MDI
B J1962 Diagnostic connector
C USB cable
D Ethernet cable
E AC adapter/power supply
Wireless interface
AAA batteries
Owner manual
Operating software for the MDI will be downloaded from the TS2WEB website.
The GM MDI allows the user to perform Pass-Thru programming procedures using software running on a laptop or desktop PC.
