MECHANICAL JUMPER CLAMPS
• Two sizes available - 6 solid through 556.5 MCM and 6 solid through 954 ACSR
• Easy to install
• Thrust bearing design provides low friction for tightening clamp
• Bronze clamping rings have serrated contact surface to insure good electrical contact with conductors
• Two styles available...
Yellow handles are made from bright yellow, impact resistant modified polyolefin material
Clear handles are made from a high impact plastic material
• Grip tabs are molded in for easy gripping with rubber gloves
• Conductor clamp is machined from brass alloy
• Rated for 400 amps continuous current maximum rating - this rating is dependent on the rating of the
jumper cable used with the clamps
![2013072550301081[1]](http://i05.c.aliimg.com/img/ibank/2013/636/919/1049919636_1086601265.jpg)
CAT NO | DEscriptION | MAIN LINE RANGE | JUMPER CABLE RANGE | LBS | ||
|
| MAXIMUM | MINIMUM | MAXIMUM | MINIMUM |
|
13004 | MEDIUM RANGE JUMPER CLAMP YELLOW | 556-5 MCM OR 477 ACSR | 6 SOLID .162 DIA | 4/0 15KV* | #2 | 1.6 |
13765 | MEDIUM RANGE JUMPER CLAMP CLEAR | 556-5 MCM OR 477 ACSR | 6 SOLID .162 DIA | 4/0 15KV* | #2 15KV | 1.6 |
11000 | LARGE RANGE JUMPER CLAMP YELLOW | 954 ACSR 36/1 | 6 SOLID .162 DIA | 4/0 15KV 1/0 35KV | #2 | 2.7 |
13768 | LARGE RANGE JUMPER CLAMP CLEAR | 954 ACSR 36/1 | 6 SOLID .162 DIA | 4/0 15KV 2/0 25KV 1/0 35KV | #2 15KV | 2.7 |
*NOTE: CLAMPS WILL ACCOMMODATE 4/0 STR. 15KV CABLE onLY IF EPR (ETHYLENE, PROPYLENE RUBBER) INSULATED CABLE IS USED. | ||||||
**NOTE: IF 25KV OR 35KV CABLE IS REQUIRED LARGE RANGE CLAMPS MUST BE USED. | ||||||
