DHG型 電熱恒溫鼓風乾燥箱 (DHG Series Heating and Drying Oven)

一、用途概述
供工礦企業、化驗室外、科研單位等作乾燥、烘焙、熔臘、滅菌之用。
二、產品特點
1 、工作室采用優質鋼板或不銹鋼板。
2 、微電腦智慧控溫機，具有設定，測定溫度雙數字顯、定時、功率抑制和自整定功能，控溫精確可靠。
3 、熱風循環系統由低噪聲風機和風道組成，工作室內溫度均勻。
I.Applications:
It is applicable to such test as drying,cure melt,sterilize in industrial and mining enterprises as well as in laboratory and scientific research institute.
II.Features:
1 、 The working chamber is made of high quality sheet steel or corrosion-restistant stainless steel,safe and easy to use.
2 、 Intelligent temperature controller is based microprocessor with PID parameters controlling function.Digital display of set and actual temperatures. High temperature controlling accuracy and reliability.
3 、 Hot air circulation system is consist of low-noisy fan and optimal air duct, reaching a uniform temperature inside the working chamber

註： ① DHG 型產品均有定時功能，定時范圍： 0~9999min ，控溫精度 0.1 ℃ , 溫度波動 ± 1 ℃ , “ RT” 表示室溫 .
② 除 9623A 、9426A、9626A 、9149A電源電壓為 380V ， 50H 外其餘均為 220V ， 50Hz 。
③ （ A ）表示包括帶 A 和不帶 A 兩種型號產品，帶 A 為不銹鋼工作室帶觀察窗，不帶 A 為鍍鋅或一般鋼板不帶觀察窗。

Notes: ① DHG Series has timing function. And the range of timing is 0 to 999min. The temperature control precision is 0.1 ℃ . and the temperature fluctuation is ± 1 ℃ ,”RT” stands of room temperature,
② Except main voltage of model 9623A 、 9426A and 9626A are 380V,59Hz, the others are 220v,50Hz.
③ (A)have “A”andnothave“A”. and “A” means stainless steel working chamber, has the window in the door. The not have means zinc or ordinary steel working chamber, has not window.

GRX型 乾熱消毒箱 Model GRX Hot —— air Sterilizer

一、用途概述：
供工礦企業、化驗室科研單位和大專院校等作乾燥、烘焙、消毒、滅菌之用。
二、產品特點：
是利用高溫乾熱對微生物有氧化、蛋白質變性、電解質濃縮引起中毒等作用，而且在一定時間內可殺死一切微生物。
1 、 直觀精確：微電腦智能控溫機，具有設定、測定溫度雙數字顯示、控溫精確可靠。
2 、 安全方便：二套安全獨立的控溫系統，定時控溫、報警切斷加熱電源、確保人員安全。

I.Applications:
It is applicable to such test as drying , cure, melt, sterilizing in industrial and mining enterprises as well as in laboratory, scientific research institute, medical college and universities.

Ii Features:
It is to utilize the effects of poisoning caused by oxidation of microorganisms, denaturizing of protein and concentration of electrolyte under

三、技術參數（ Specifications ）
