The John Guest PE Range of plastic tubing is produced in Linear Low Density Polyethylene. Our tubing provides the benefits of a wide range of temperature and pressure suitability, broad chemical compatibility and is made from non contaminating materials. Common applications are in water purification, water conditioners, ice makers and misting systems. LLDPE is more robust than traditional low or medium density polyethylene and is recommended for use with cold and intermittent hot water. Our tubing is made from FDA approved materials and is NSF International certified. John Guest Polyethylene tubing is designed for use with John GuestSuper Speedfitpush-in fittings, John Guest Shut-Off Valves and virtually all standard tubing connectors. |
|
LLDPE Tubing
SIZES AVAILABLE | ||||
Part No. | OD | ID | Coil Length | Min Bend Radii |
PE-08-BI-0500F-N | 1/4"(0.250") | 0.170" | 500 FT | 1.00" |
PE-08-BI-1000F-N | 1/4"(0.250") | 0.170" | 1000 FT | 1.00" |
PE-10-CI-0500F-N | 5/16"(0.312") | 0.187" | 500 FT | 1.13" |
PE-12-EI-0500F-N | 3/8"(0.375") | 0.250" | 500 FT | 1.25" |
PE-16-GI-0250F-N | 1/2"(0.500") | 0.375" | 250 FT | 2.50" |
PE-04025-0100M-N | 4mm | 2.5mm | 100m | 25mm |
PE-0604-0100M-N | 6mm | 4mm | 100m | 25mm |
PE-0806-0100M-N | 8mm | 6mm | 100m | 30mm |
PE-1007-100M-N | 10mm | 7mm | 100m | 32mm |
PE-1209-100M-N | 12mm | 9mm | 100m | 63mm |
PE-15115-0100M | 15mm | 11.5mm | 100m | 100mm |
N denotes natural colour. To request other colours please refer to table below.
Popular items are now generally in stock and are available in minimum quantities of 2 coils. Other items may be subject to longer lead times and are available in minimum of 50 coils.
STANDARD COLOURS AVAILABLE | |
SUFFIX | COLOUR |
N | Natural |
B | Blue |
E | Black |
R | Red |
Other special colours available on request :- | |
Orange (O) | Green (G) |
Violet (V) | Yellow (Y) |
White (W) | |
