商品代碼:3089432

  • 2013最新太陽能柔性版 太陽能光伏發電板 太陽能組件 SYK30-18M
    商品代碼: 3089432
    (可點擊以下立即詢價直接線上諮詢,或來電提供此商品代碼諮詢)
    即日起提供日本樂天代購服務-詳見 Rakuten-suki日本樂天代購,謝謝。
    商品詳細說明
    加工定制:是 品牌:OCEAN 型號:SYK30-18M
    類型:層壓太陽能電池板/組件 最大功率:30(W) 工作電流:1.67(A)
    工作電壓:18(V) 系統電壓:1000(V) 開路電壓:21.24(V)
    短路電流:1.83(A) 電池數量:36(個,隻) 外形尺寸:630*440*2.5(mm)
    參考重量:1.14(KG) 產品認證:CE&ROHS









    30W semi-flexible solar panel kit for yacht boat RV, boat ready for using. The revolution on producing technology of solar panel, cut 70% weight from the standard rigid solar panel

    1.Flexible Solar Panel Electrical Technical Data:

    Model NO                                                                                            SYK30-18M

    Peak Power(Pmax)                                                                 30(W)

    Production Tolerance                                                             ±3%

    Maximum Power Voltage (Vmp)                                        18V

    Maximum Power Current (Imp)                                                      1.67A

    Open Circuit Voltage (Voc)                                                  21.24V

    Short Circuit Current (Isc)                                                      1.83A

    Maximum System Voltage                                                 DC 1000V

    Solar Cell Type                                                                                Mono

    Solar Cell Efficiency                                                                       16.8%

    AII technical data at standard test conditionAM=1.5E=1000W/Tc=25°C

    2.Flexible Solar Panel Size&Packing:

    Length                                                                                        630mm

    Width                                                                                           440mm

    Depth                                                                                          2.5mm

    Net Weight                                                        5.07KGS

    Outer Packing Size5PCS/CTN)                                         705*515*200mm

    Gross Weight                                              8KGS

    Q'ty/20' container                                                             PCS

    Q'ty/40HQ container                                                           PCS

    3.MainFeatures:

    1). Semi flexible : bending angle up to 30 degrees

    2).Durable with aluminum backsheet, no glass

    3).Light weight for easy carry.

    4).The thickness only 2.5mm, easy joint to your yacht or RV roof.

    5).High efficiency monocrystalline solar panel





    pictures:
