    東莞溫控開關|東莞KSD301溫控器生產廠傢銷售
    商品代碼: 3088375
    (可點擊以下立即詢價直接線上諮詢,或來電提供此商品代碼諮詢)
    即日起提供日本樂天代購服務-詳見 Rakuten-suki日本樂天代購,謝謝。
    商品詳細說明
    加工定制:是 品牌:TKK 型號:KSD
    工作電壓:250(V) 過載電流:1(A) 動作溫度:1(℃)
    壽命:10000000(次) 產品認證:全



    溫控開關專業生產商--臺灣亮群     交期: 7-15天交貨

    產品圖紙連接網站地址:http://www.lightcountry.com/chinese/thermostat.htm

    交期:7-15天內交貨,歡迎來電洽談、索樣、訂購。

    本司專業從事開關生產26年歷史,是一傢臺灣品牌開關生產廠傢,大陸工廠在廣東省東莞市

    Thermostat Switches (10A, 250VAC) with UL, VDE, FI, NSD Approvals

    Electrical rating:15A 125VAC (resistive load) 10A 250VAC (resistive load)

    Operating temperature: 50 to 200 degrees Celsius (UL, cUL, 205 degrees Celsius)

    Differential:10 to 30 degrees Celsius

    Operating temperature: +/-5 degrees Celsius (+/-3 degrees Celsius available) or +/-4.5%(100 to 200 degrees Celsius)

    Recovery temperature:+/-10 oC (or +/-6%)(100 to 200 degrees Celsius)

    Weight: 4.2g (4 poles), 4g (short one)

    Heat durability:240 degrees Celsius (PPS) and 150 degrees Celsius phenolic

    Circuit resistance:50m ohms or less

    Insulation resistance:100M ohms or more between the non-live metal parts and terminals

    Dielectric strength:AC 1,000V for one minute or more between non-live metal parts and terminals

    Operating life:100K cycles (at full load)
