品代號ProductCode number

鋼絲層Steelwire level

工作壓力Operating p.

PSL

規格 Specification

最小彎曲MmMin.bendingradius

內徑 mmInside diameter

外徑 mmOuterdiameter

GPA — 4

1

40

5800

4

9

70

2

60

8700

4

10.6

75

GPA — 6

1

33

4800

6

11

80

2

50

7250

6

12.5

85

GPA — 8

1

25

3600

8

13.1

105

2

38

5500

8

15.1

120

GPA — 10

1

22

3200

8

15.4

105

2

32

4600

10

16.8

120

GPA — 12

1

18

2600

12

17.7

150

2

27

3900

12

19.1

160

GPA — 16

1

14

2000

16

21.8

180

2

21

3000

16

23.4

190

GPA — 19

1

12

1700

19

25.1

200

2

18

2600

19

26.7

210

GPA — 22

1

10

1450

22

28.3

220

2

15

2200

22

29.9

230

GPA — 25

1

9

1300

25

31.5

250

2

14

2000

25

33.1

260

GPA — 32

1

8.5

1200

32

40

320

2

12

1700

32

43

320

GPA — 38

1

7

1000

38

47

380

2

10

1450

38

49

380

GPA — 45

1

6.5

900

45

54

450

2

9

1300

45

56

450

GPA — 51

1

6

870

51

61

520

2

8

1100

51

63

520
