EM-6B2是用於非焊接電氣接線的壓接，具有省力、快捷等優點，是替代手動壓接鉗的最佳選擇，適用截麵范圍在0.25mm2至10mm2之間的冷壓端頭及剪切端子功能。隨機配備7套精密的壓線模，可隨時根據需要更換壓線模具，工作效率高、適應性強。
本產品采用定速馬達驅動，無論是在壓接力量上或壓接速度上都具有高效率與高品質的優點，適用於中大數量端子壓接使用，如果所需壓接端子形式多樣的話，更需選擇本產品。
本產品通過CE認證，已申請外觀專利。
Type EM-6B2 is an ideal crimper for connection in cabinet.It is applicable for pre-insulated terminal crimping from 0.25mm2 to 10mm2 and Cu/Al cutting in 7mm. It is supplied with seven kinds of accurate and replaceable die sets. The crimper has high working efficiency and wide application.
The crimper is driven by fixed speed motor so that it owns advantages of high efficiency and high quality not only in crimping force but crimping speed. It is good for terminal crimping in large or medium quantity. If there are a lot of different kinds of terminals to be crimped, this crimper is the best choice.
本產品采用雙作用標準氣缸驅動，在壓接力和壓接速度上具有高效率與高品質的優點。極適用於中、大數量之端子壓接使用。如果所需壓接端子形式多樣，更應選擇本產品！AM-10與本公司所生產的手工壓接鉗的夾具有著良好的互換性。且備有多種樣式的端子壓接夾具可供選購。
隨機附件：口模1副，腳踏氣閥1隻，氣管2條
The machine is driven by dual-action normal cylinder, which has advantages of high efficiency and quality in crimping force and speed. The machine is fit for crimping many kinds of terminals. The die sets are interchangeable with our manual crimping tools. So we can provide you all kinds of die sets for crimping.
Accessories: one die set, one foot air valve, two air pipes.
EM-6B2
0.25-10
AC 220/110
12.7
325×265×150
12
型號
壓接能力
電壓范圍
出力
外形尺寸
重量
Item No.
Capacity (mm2)
Voltage range (V)
Output (KN)
Overall dimension (mm)
Weight (kg)
AM-10
0.08-10
0.4-1.0
13.5
260×120×140
4
型號
壓接能力
氣壓范圍
出力
外形尺寸
重量
Item No.
Capacity (mm2)
Air pressure range (Mpa)
Output (KN)
Overall dimension (mm)
Weight (kg)
