產品概述
DL型立式多級離心泵是我公司根據我國對高層建築給排水及國傢消防局GB6245-98標準開發的新產品。該型泵由於采用瞭高效節能的優秀水力模型,因此具有效率高,性能范圍廣等優點,更好地滿足瞭用戶的使用要求。另外,本型泵在結構上采用瞭立式、分段形式,且運轉安全、平穩、壽命長、占地麵積小、安全維修方便。
產品用途
DL、DLR型泵適用於工業和城市給排水、高層建築增壓、遠距離送水、采暖、浴室、鍋爐冷暖水循環增壓、空調制冷系統送水及設備配套等場合。DL型介質使用溫度不超過80°C,DLR型介質使用溫度不超過120°C。
型號意義
例如:80DL(DLR)*4
80-泵吸入口公稱直徑(mm)
DL-立式多級分段式離心泵
DLR-立式多級分段式熱水離心泵
4-泵級數
DL型立式多級離心泵性能參數表 |
型號 | 級數 | 流量 (m3/h) | 流量 (L/S) | 揚程 (m) | 軸功率 (kw) | 電機功率(kw) | 效率 (%) | 吸程 (m) | 汽蝕餘量 (m) |
40DL | 2 | 6.2 | 1.72 | 23.6 | 0.92 | 1.5 | 40 | 7 | 3.19 |
3 | 6.2 | 1.72 | 35.4 | 1.38 | 2.2 | 40 | 7 | 3.19 |
4 | 6.2 | 1.72 | 47.2 | 1.84 | 3 | 40 | 7 | 3.19 |
5 | 6.2 | 1.72 | 59 | 2.30 | 4 | 40 | 7 | 3.19 |
6 | 6.2 | 1.72 | 70.8 | 2.75 | 4 | 40 | 7 | 3.19 |
7 | 6.2 | 1.72 | 82.6 | 3.22 | 5.5 | 40 | 7 | 3.19 |
8 | 6.2 | 1.72 | 94.4 | 3.68 | 5.5 | 40 | 7 | 3.19 |
9 | 6.2 | 1.72 | 106.2 | 4.14 | 7.5 | 40 | 7 | 3.19 |
10 | 6.2 | 1.72 | 118 | 4.60 | 7.5 | 40 | 7 | 3.19 |
11 | 6.2 | 1.72 | 129.8 | 5.06 | 7.5 | 40 | 7 | 3.19 |
12 | 6.2 | 1.72 | 141.6 | 5.52 | 11 | 40 | 7 | 3.19 |
50DL | 2 | 12.6 | 3.5 | 24.4 | 1.55 | 3 | 54 | 7.6 | 2.66 |
3 | 12.6 | 3.5 | 36.6 | 2.33 | 3 | 54 | 7.6 | 2.66 |
4 | 12.6 | 3.5 | 48.8 | 3.10 | 4 | 54 | 7.6 | 2.66 |
5 | 12.6 | 3.5 | 61 | 3.88 | 5.5 | 54 | 7.6 | 2.66 |
6 | 12.6 | 3.5 | 73.2 | 4.65 | 5.5 | 54 | 7.6 | 2.66 |
7 | 12.6 | 3.5 | 85.4 | 5.43 | 7.5 | 54 | 7.6 | 2.66 |
8 | 12.6 | 3.5 | 97.6 | 6.20 | 7.5 | 54 | 7.6 | 2.66 |
9 | 12.6 | 3.5 | 109.8 | 6.98 | 11 | 54 | 7.6 | 2.66 |
10 | 12.6 | 3.5 | 122 | 7.75 | 11 | 54 | 7.6 | 2.66 |
65DL | 2 | 30 | 8.33 | 32 | 4.22 | 5.5 | 62 | 7.6 | 2.82 |
3 | 30 | 8.33 | 48 | 6.33 | 7.5 | 62 | 7.6 | 2.82 |
4 | 30 | 8.33 | 64 | 8.44 | 11 | 62 | 7.6 | 2.82 |
5 | 30 | 8.33 | 80 | 10.55 | 15 | 62 | 7.6 | 2.82 |
6 | 30 | 8.33 | 96 | 12.66 | 15 | 62 | 7.6 | 2.82 |
7 | 30 | 8.33 | 112 | 14.77 | 18.5 | 62 | 7.6 | 2.82 |
8 | 30 | 8.33 | 128 | 16.88 | 22 | 62 | 7.6 | 2.82 |
9 | 30 | 8.33 | 144 | 18.99 | 22 | 62 | 7.6 | 2.82 |
10 | 30 | 8.33 | 160 | 21.1 | 30 | 62 | 7.6 | 2.82 |
80DL | 2 | 50.4 | 14 | 40 | 7.84 | 11 | 70 | 7.8 | 22.49 |
3 | 50.4 | 14 | 60 | 11.76 | 15 | 70 | 7.8 | 2.49 |
4 | 50.4 | 14 | 80 | 15.68 | 22 | 70 | 7.8 | 2.49 |
5 | 50.4 | 14 | 100 | 19.60 | 30 | 70 | 7.8 | 2.49 |
6 | 50.4 | 14 | 120 | 23.52 | 30 | 70 | 7.8 | 2.49 |
7 | 50.4 | 14 | 140 | 27.44 | 37 | 70 | 7.8 | 2.49 |
8 | 50.4 | 14 | 160 | 31.36 | 45 | 70 | 7.8 | 2.49 |
9 | 50.4 | 14 | 180 | 35.28 | 45 | 70 | 7.8 | 2.49 |
10 | 50.4 | 14 | 200 | 39.20 | 55 | 70 | 7.8 | 2.49 |
100DL-72-20 | 2 | 72 | 20 | 40 | 10.9 | 15 | 72 | 8 | 2.8 |
3 | 72 | 20 | 60 | 10.9 | 18.5 | 72 | 8 | 2.8 |
4 | 72 | 20 | 80 | 10.9 | 30 | 72 | 8 | 2.8 |
5 | 72 | 20 | 100 | 10.9 | 37 | 72 | 8 | 2.8 |
6 | 72 | 20 | 120 | 10.9 | 37 | 72 | 8 | 2.8 |
7 | 72 | 20 | 140 | 10.9 | 45 | 72 | 8 | 2.8 |
8 | 72 | 20 | 160 | 10.9 | 55 | 72 | 8 | 2.8 |
9 | 72 | 20 |
