| 加工定制：是 | 型號：PCLDP系列 | 規格：1/4 |
| 類型：波浪管 | 材質：鐵 | 表麵處理：拋光 |
| 公稱通徑：00（mm） | 緊固直徑：00（mm） | 適用范圍：皆可 |
| 品牌：KT |
| 不包膠型 | ||||||
| 訂貨號 | 內徑 | 螺釘孔徑 | 寬度 | 厚度 | ||
| PCLD | PCLI | PCLR | ||||
| PCLD006 | PCLI006 | PCLR006 | 11 | 6.6 | 15 | 1.0 |
| PCLD007 | PCLI007 | PCLR007 | 14 | 6.6 | 15 | 1.0 |
| PCLD008 | PCLI008 | PCLR008 | 16 | 6.6 | 15 | 1.0 |
| PCLD010 | PCLI010 | PCLI010 | 18 | 6.6 | 15 | 1.5 |
| PCLD011 | PCLI011 | PCLI011 | 22 | 6.6 | 15 | 1.5 |
| PCLD012 | PCLI012 | PCLI012 | 27 | 6.6 | 15 | 1.5 |
| PCLD013 | PCLI013 | PCLI013 | 32 | 6.6 | 15 | 2.0 |
| PCLD014 | PCLI014 | PCLI014 | 40 | 6.6 | 15 | 2.0 |
| PCLD015 | PCLI015 | PCLI015 | 47 | 6.6 | 15 | 2.0 |
| PCLD016 | PCLI016 | PCLI016 | 60 | 6.6 | 15 | 2.5 |
| PCLD017 | PCLI017 | PCLI017 | 76.8 | 6.6 | 15 | 2.5 |
| PCLD018 | PCLI018 | PCLI018 | 86.5 | 6.6 | 15 | 2.5 |
| PCLD019 | PCLI019 | PCLI019 | 111.5 | 6.6 | 15 | 3.0 |
| 包膠型 | ||||||
| 訂貨號 | 內徑 | 螺釘孔徑 | 寬度 | 厚度 | ||
| PCLDP | PCLIP | PCLRP | ||||
| PCLDP006 | PCLIP006 | PCLRP006 | 9 | 6.6 | 15 | 1.0 |
| PCLDP007 | PCLIP007 | PCLRP007 | 12 | 6.6 | 15 | 1.0 |
| PCLDP008 | PCLIP008 | PCLRP008 | 14 | 6.6 | 15 | 1.0 |
| PCLDP010 | PCLIP010 | PCLRP010 | 16 | 6.6 | 15 | 1.5 |
| PCLDP011 | PCLIP011 | PCLRP011 | 20 | 6.6 | 15 | 1.5 |
| PCLDP012 | PCLIP012 | PCLRP012 | 25 | 6.6 | 15 | 1.5 |
| PCLDP013 | PCLIP013 | PCLRP013 | 30 | 6.6 | 15 | 2.0 |
| PCLDP014 | PCLIP014 | PCLRP014 | 38 | 6.6 | 15 | 2.0 |
| PCLDP015 | PCLIP015 | PCLRP015 | 45 | 6.6 | 15 | 2.0 |
| PCLDP016 | PCLIP016 | PCLRP016 | 58 | 6.6 | 15 | 2.5 |
| PCLDP017 | PCLIP017 | PCLRP017 | 73.5 | 6.6 | 15 | 2.5 |
| PCLDP018 | PCLIP018 | PCLRP018 | 84.5 | 6.6 | 15 | 2.5 |
| PCLDP019 | PCLIP019 | PCLRP019 | 109.5 | 6.6 | 15 | 3.0 |
