W. No.	N/S		UNS No.	N/S
AISI No.	N/S		EN	N/S

Vancron 40

Vancron 40 is a nitrided powder metallurgical tool steel offering an excellent combination of galling resistance and adhesive wear resistance. Vancron 40 is ideal for severe production conditions and / or long run production in applications where surface coated tool steel is needed in order to solve the above tooling problems.

Due to the powder manufacturing route used, Vancron 40 has a superior machinability compared to similar conventionally produced grades. The dimension stability during heat treatment is good, and in opposite to other conventionally produced high alloyed steels, also predictable. However, the big advantage with Vancron 40 is that it is designed to be used without surface coating. This is possible due to high amounts of vanadium rich nitrides in the matrix.

Benefits:

•  Longer tool life, improved overall economy and less maintenance and tool failure disturbances due to the excellent galling / adhesive wear properties

•  Longer production runs and more parts produced due to the unique low friction surface properties





•  Vancron 40 is designed to replace surface coated tool steel, when surface coating is used to reduce galling and adhesive wear.





•  The excellent galling / adhesive wear properties guarantees high and uniform quality from the first to the last part produced










  Properties:




•  Very high adhesive wear resistance
•  Very high galling resistance
•  Good chipping and cracking resistance
•  High compressive strength
•  Good through hardening properties
•  Good dimension stability in hardening
•  Very good resistance to tempering back
•  Good WEDM properties



  Applications:

  VANCRON 40 should be used in cold work applications where the work material is soft and adherent  and tends to gall or stick to the tool surface like austenitic and ferritic stainless steels, mild steels, ultra high strength steels, copper or aluminium.


•  Blanking and forming
•  Fine blanking
•  Cold Extrusion
•  Deep drawing
•  Powder pressing
•  An alternative to surface coating to prevent galling and adhesive wear
•  An alternative to hard metal and FerroTiC (where these are used to prevent galling)
•  An alternative to Aluminium-bronze in cold work applications
