Item

Description

Dimension

115*115*26mm

System Config.

CPU

AmlogicS812Quad Core up to 2.0GHz (Cortex-A9)

GPU

Octa core ARM Mali-450 GPU up to 600MHz

RAM

DDR3 2GB

ROM

Onboard eMMC Flash 16GB

Bluetooth

BT 4.0

Expand Memory

Micro SDCard (Maximum support 32GB)

Antenna

Built-in antenna for WIFI

Media

UHD4K×2K

Yes Support

Full HD 1080P

Yes Support

HEVC H.265

Yes Support

Video/Picture Decoding

Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats

Audio format

Support: MP3, AAC, WMA, RM, FLAC, OGG

Communication

Ethernet

1000M LAN

WIFI

IEEE 802.11a/b/g/n

IEEE 802.11a/b/g/n, WiFi compliant

2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band)

4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band)

Sensor/Motor

IR Sensor

1*IR

Indicator

Power LED

1* power LED with two - color

Button & Ports

Button

1*Power Button

1*updat Button(via one pin hole)

USB2.0

2* Standard USB

1*Micro USB with OTG

DC-in

1*DC in Jack

HDMI

1*HDMI A Type

SPDIF

1*S/SPDIF (2CH, 5.1CH)

RJ45

1*RJ45

TF Card Slot

1* Micro SD card slot

AV

1*AV Port

Power management

Adapter

5V 2A

Software Config.

OS

Google Android 5.1

Language

Multi -language

Keyboard

Qwerty keyboard

Features

Miracast/DLNA

Support

UI

Support original ecology and custom UI

Work Environment

5°C--35°C，30%--90%Humidity

Storage Environment

-20°C--60°C，10%--90%Humidity
