SZL型散熱器是一種新型高效的空氣換熱器，它采用瞭先進的復合工藝技術，具有最佳的換熱效果。是以高溫熱水、蒸汽或導熱油為熱媒進行空氣加熱裝置的最佳選擇，該種散熱器在化工、製藥、紡織印染、塗裝烤漆、化纖、橡膠、塑膠PVC、皮革、木材、印花等行業得到廣泛應用。

  SZL型散熱器翅片管一般有φ18x2.0-38、φ21x2.5-51、φ25x2.5-51等多種規格，不同的表麵管數、排數和管長可以組成多種規格的散熱器。熱媒的流動可以單流程或多流程，工作壓力一般為2.5Mpa以下，工作溫度350℃以內。

  SZL型散熱器復合翅片管的基管材質可以是碳鋼、不銹鋼、銅、鈦材等。雙金屬緊密復合後，散熱管具有接觸熱阻小、傳熱性能好、強度高、通風阻力小、不易結塵、防腐性能強、外形美觀、工作壽命長等特點。

SZL type radiator is a new type of high efficient air heat exchanger, it adopts thecomposite advanced technology, has the best heat exchange effect. Is the best choice for high temperature hot water, steam or thermal oil as heat medium for airheating device, the radiator is widely used in chemical, pharmaceutical, textile printing and dyeing, coating paint, chemical fiber, rubber, plastics, leather, wood, PVC,printing and other industries.

SZL type radiator fin tubes are generally phi18x2.0-38, Phi21x2.5-51, Phi25x2.5-51wait for a variety of specifications, different surface tube number, row number and length can be composed of a variety of specifications of the radiator. Heat mediumflows or more single process flow, operating pressure is generally below2.5Mpa,within the working temperature of350 DEG C.

SZL type composite finned tube radiator base pipe material can be carbon steel,stainless steel, copper, titanium etc.. Double metal composite closely, heat pipe has the contact thermal resistance, good heat transfer performance, high strength, small ventilation resistance, not easy to knot characteristics of dust, strong anti-corrosion,beautiful app

產品圖
