主要用於鋁合金幕墻料．窗料的切割下料，亦可用於塑料型材的切割下料，使用硬質合金鋸片，外徑可達Ø500，線速度高，加工精度高。機床工作時，兩鋸頭鋸片可同時進行切割,亦可單獨切割。鋸頭可擺成90°和45°的需要角度，鋸片由下向上，鋸切型材更安全可靠，而且鋸切高度和鋸切寬度都很大。本機床可帶數顯裝置和數控系統，因而更適合鋁門窗、鋁幕墻料的切割。
Mainly used for cutting and laying off aluminum alloy curtain wall materials and window profile,and also used for cutting and laying off plastic profile. It utilizes hard alloy saw blade for diameter as big as Ø500 as well as high linear speed and high processing precision,When the two sawing units can cut profiles simultaneously or separately; the saw blade can swing to required angle between 90°and 45°.
The saw blade cut the profile from bottom to top safely and reliably, and the cutting height and width is enough.
The machine tool can equipped with digital display and CNC System unit. MAIN TECHNIQUE PARAMETER 鋸片長度 Saw blade length 450-4200mm 鋸切寬度X高度（bxh) Cutting width X height (bxh) 230120mm | 主電機功率Main motor power | 2.2KMx2 | 主電機轉速Main motor rotation speed | 2840r/min | 使用鋸片尺寸Saw blade dimension | φ500xφ30Xφ120T | 鋸片可擺動角度Saw blade swing angle | 90°- 45° | 鋸片進給速度Saw blade feeding speed | 0-3m/min | 鋸片返回速度Saw blade returning speed | 2-3m/min | 工作氣壓Working air pressure | 0.6-0.8Mpa | 工作電壓Working voltage | 380V 50Hz | 外形尺寸（長x寬x高） Over all dimension(L x W X H) | 54601350x1380mm | 機床重量Weight | 2000kg |
|
